Cisco

Cisco C2951-VSEC/K9 | 2951 Router, PVDM3-32, UC & SEC Licence, CUBE 5

C2951-VSEC/K9

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Cisco 2951 Voice and Security Bundle is a pre-configured Integrated Services Router package from the Cisco 2900 Series ISR G2 range. It is built for branch-office and small-to-medium enterprise sites that need secure WAN routing together with voice services such as SRST and CCME call survivability, DSP-based voice and video, and CUBE session border functions.

The 2951 chassis provides 3 onboard 10/100/1000 WAN ports, one of which is SFP-based and shares with an RJ-45 port. Expansion comes from 4 EHWIC slots (2 double-wide), 2 Service Module slots (1 double-wide), 1 ISM slot and 3 onboard PVDM slots. This SKU includes a PVDM3-32 DSP module, the Cisco IOS Unified Communications (UC) and Security (SEC) licence PAKs, and a CUBE 5 licence. Embedded hardware crypto acceleration supports IPsec VPN with the Security licence. It ships with 512 MB DRAM and 256 MB Compact Flash, expandable to 2 GB and 4 GB, and is a 2RU unit with 100 to 240 VAC auto-ranging input.

It accepts EHWIC, HWIC, WIC, VIC and VWIC interface cards, single and double-wide Service Modules, and PVDM3 DSP modules, with PVDM2 supported through an adapter. It also works with the external Cisco RPS 2300.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Highly modular platform with EHWIC, Service Module, ISM and PVDM3 slots
- Embedded hardware encryption acceleration for IPsec VPN, used with the Cisco IOS Security licence
- Voice and video capable DSP slots, PVDM3 native with PVDM2 via adapter
- Supports IPv4, IPv6, OSPF, EIGRP, BGP, IS-IS, MPLS, IPsec and GRE
- Supports QoS, PBR, PfR and NBAR for traffic management
- Optional firewall, intrusion prevention, call processing and voicemail services
- Integrated power distribution to modules supporting 802.3af PoE and Cisco Enhanced PoE
- Two external Compact Flash slots and two USB 2.0 ports for storage and secure token

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Onboard WAN ports: 3 x 10/100/1000 (1 SFP-based, shares with an RJ-45 port)
- DSP: PVDM3-32 module, 3 onboard PVDM slots
- EHWIC slots: 4 (2 double-wide)
- Service Module slots: 2 (1 double-wide)
- ISM slots: 1
- DRAM: 512 MB default, 2 GB maximum
- External Compact Flash: 256 MB default, 4 GB maximum
- USB: 2 x USB 2.0 Type A
- Console: USB Type B and serial console, plus serial auxiliary port
- SRST sessions: 250
- CCME sessions: 150
- Cryptography: embedded hardware-based acceleration
- AC input: 100 to 240 VAC auto-ranging, 47 to 63 Hz
- Typical power (no modules): 70 W
- Maximum power with AC supply: 340 W
- Dimensions (H x W x D): 88.9 x 438.2 x 469.9 mm
- Rack height: 2RU, 19-inch EIA mounting
- Weight with AC power supply (no modules): 13.2 kg
- Airflow: back and side to front
- Operating temperature: 0 to 40 C (up to 3,000 m)
- Operating relative humidity: 5 to 85%

FAQs

Q: Which licences does this bundle include?
A: It includes the Cisco IOS Unified Communications (UC) and Security (SEC) licence PAKs and a CUBE 5 licence. Data and AppX technology packages are separate licences.

Q: How does this bundle differ from a standard Cisco 2951 router?
A: This SKU adds the PVDM3-32 DSP module, the UC and SEC licence PAKs and the CUBE licence to the 2951 chassis, so voice and security features are ready to enable.

Q: What modules does it work with?
A: It accepts EHWIC, HWIC, WIC, VIC and VWIC cards, single and double-wide Service Modules, ISM modules and PVDM3 DSP modules. AIM modules are not supported.

Q: Can it provide PoE?
A: PoE comes from an optional AC PoE power supply, which provides up to 370 W of end-point PoE, or up to 750 W with PoE Boost using an external Cisco RPS 2300.

Q: How many SRST and CCME sessions does the 2951 support?
A: The 2951 platform supports up to 250 Cisco Unified SRST sessions and up to 150 Cisco Unified CCME sessions.
