Cisco C2951-UCSE-K9 | ISR 2951 Router, SRE 900/910, SRE-V, 4 GB DRAM

C2951-UCSE-K9

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Cisco ISR 2951 UCS Express bundle is built on the Cisco 2900 Series Integrated Services Router G2 platform. It pairs the router with a Services Ready Engine (SRE 900 or SRE 910) service module and the SRE-V hypervisor licence, so branch offices can run virtualised application and server workloads alongside routing, voice and security on one integrated platform.

This bundle ships in a 2951, SRE 900/910, SRE-V configuration with 4 GB ISR DRAM and 768 MB ISR Compact Flash, with IMC Express software included. It provides three onboard 10/100/1000 WAN ports, one of which can be used as an SFP, along with four EHWIC slots (two double-wide), two service module slots (one double-wide), three onboard DSP (PVDM) slots and one ISM slot. Embedded hardware-based cryptography and acceleration is built in, and concurrent services WAN performance is up to 75 Mbps. Cisco Unified SRST supports up to 250 sessions and Unified CCME up to 150 sessions. This SKU does not include the ES24 switch module or WAAS.

It works with Cisco 2900 ISR modules including EHWIC, PVDM, ISM and service modules, and the optional Cisco RPS 2300 for power redundancy or PoE boost. UCS Express on the 2951 requires at least 1.5 GB ISR DRAM and 512 MB or 256 MB Compact Flash, both met by this bundle.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- SRE 900 or SRE 910 service module with SRE-V hypervisor for running virtualised server workloads on the router
- IMC Express software included for managing the UCS Express environment
- Optional VMware vCenter Server management agent
- Multigigabit Fabric (MGF) for module-to-module communication
- TDM interconnectivity fabric for scaling DS-0 channel capacity
- Embedded IPSec VPN hardware acceleration, with security licence optional
- USB console port in addition to the traditional console and auxiliary ports
- Single Cisco IOS Universal image with technology sets activated by software licence

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Platform: Cisco 2951 ISR G2
- Bundle: UCS Express with SRE 900 or SRE 910 service module
- Hypervisor licence: SRE-V
- Management software: IMC Express
- ISR DRAM in this bundle: 4 GB
- ISR Compact Flash in this bundle: 768 MB
- Onboard WAN ports: 3 x 10/100/1000 (RJ-45)
- SFP ports: 1 (using the SFP disables the corresponding RJ-45 port)
- Service module slots: 2 (1 double-wide)
- EHWIC slots: 4 (2 double-wide)
- ISM slots: 1
- Onboard DSP (PVDM) slots: 3
- Concurrent services WAN performance: up to 75 Mbps
- Cisco Unified SRST sessions: 250
- Cisco Unified CCME sessions: 150
- Embedded hardware-based cryptography and acceleration: Yes
- Base 2951 DDR2 ECC DRAM: 512 MB default, 2 GB maximum
- Minimum ISR DRAM for UCS Express: 1.5 GB
- Minimum ISR Compact Flash for UCS Express: 512 MB or 256 MB
- Design: NEBS environments

FAQs

Q: Does this bundle include the SRE-V hypervisor licence?
A: Yes. The bundle includes the SRE-V hypervisor licence and IMC Express software. Cisco IOS technology sets such as security, UC and data are activated with separate software licences.

Q: How does this SKU differ from other 2951 UCS Express bundles?
A: This version has an SRE 900 or SRE 910 module with SRE-V, 4 GB ISR DRAM and 768 MB Compact Flash. It does not include the ES24 switch module or WAAS.

Q: What power options are available for the 2951?
A: The 2951 supports an optional internal power supply providing 802.3af PoE and Cisco Inline Power to integrated switch modules, and an optional DC power supply. An external Cisco RPS 2300 can add redundancy using the RPS adapter, or boost PoE capacity.

Q: What modules and optics does it work with?
A: It supports Cisco 2900 ISR modules including EHWIC, PVDM, ISM and service modules, SFPs listed at cisco.com/go/2900, and the Cisco RPS 2300 with the RPS adapter.

Q: What are the minimum memory and flash requirements for UCS Express on the 2951?
A: UCS Express on the 2951 needs at least 1.5 GB ISR DRAM and 512 MB or 256 MB Compact Flash. This bundle provides 4 GB DRAM and 768 MB Compact Flash.
