• Cisco 2960 switch with black silver vented panel in C2911-WAAS-SEC-K9 ISR bundle
1 1

Cisco

Cisco C2911-WAAS-SEC-K9 | ISR 2911 Router, SRE 700/710, Sec PAK, WAAS Small

C2911-WAAS-SEC-K9

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The ISR 2911 bundle is a branch-office router from the Cisco 2900 Series ISR G2 range, built for enterprise sites that need secure WAN routing and WAN optimisation in a single 2RU chassis. It combines the 2911 router with an SRE 700 or SRE 710 service module, the Security (Sec) PAK licence and a Cisco WAAS Enterprise Small licence.

The chassis provides 3 onboard 10/100/1000 Ethernet WAN ports, 4 EHWIC slots, 2 onboard DSP (PVDM) slots, 1 ISM slot and 1 service module slot. Memory is 512 MB DDR2 ECC DRAM by default, expandable to 2 GB, with 256 MB of CompactFlash. Hardware-based VPN encryption and acceleration is built onto the motherboard. The Sec PAK activates the Security feature set, including IOS Firewall, Zone-Based Firewall, IPS, Content Filtering and IPsec VPN, while the SRE module hosts Cisco WAAS for application acceleration across the WAN.

The 2911 chassis accepts up to two SRE modules, one ISM-type and one service module type, and supports EHWICs and HWICs, PVDM DSP modules and an external redundant power supply. Voice features include Cisco Unified Border Element, CME and SRST for up to 50 sessions.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Integrated SRE service module hosting Cisco WAAS for WAN optimisation
- Sec PAK enables IOS Firewall, Zone-Based Firewall, IPS, Content Filtering and IPsec VPN
- Four EHWIC slots with double-wide EHWIC support for flexible WAN, LAN and voice configurations
- 802.3af PoE and Cisco Enhanced PoE support through optional modules
- Optional external redundant power supply with PoE boost mode
- Optional fan filter and front-to-back airflow assembly for 23-inch racks
- Cisco Unified Border Element, CME and SRST voice capabilities

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Onboard WAN ports: 3 x 10/100/1000 Ethernet (RJ-45)
- EHWIC slots: 4
- DSP (PVDM) slots: 2
- ISM slots: 1
- Service module slots: 1, populated with SRE 700 or SRE 710
- DRAM (DDR2 ECC): 512 MB default, 2 GB maximum
- Flash memory (CompactFlash): 256 MB default
- Hardware-based VPN encryption and acceleration: Yes
- Licensing: Security (Sec) PAK and WAAS Enterprise Small
- Cisco Unified SRST sessions: 50
- Cisco Unified CME sessions: 50
- Maximum SRE modules in chassis: 2 (1 x SRE 300 ISM and 1 x SRE 700/710/900/910 service module)
- SRE 700 CPU: 1.06 GHz Intel Celeron-class
- SRE 710 CPU: 1.86 GHz Intel Core2 Solo
- AC input voltage: 100 to 240 VAC auto-ranging
- AC input frequency: 47 to 63 Hz
- Dimensions (H x W x D): 3.5 x 17.25 x 12 in. (88.9 x 438.2 x 304.8 mm)
- Rack height: 2RU
- Optional power: DC-PoE power supply and external RPS
- NEBS: designed for NEBS environments

FAQs

Q: Which licences are included with this bundle?
A: The bundle includes the Security (Sec) PAK licence and a Cisco WAAS Enterprise Small licence for the SRE 700/710 module. The base IOS image is IP Base, and the Sec PAK activates the Security feature set.

Q: What does the Sec PAK enable?
A: The Sec PAK activates the Security feature set, which covers IOS Firewall, Zone-Based Firewall, IPS, Content Filtering and IPsec VPN.

Q: Can I add redundant power to the 2911?
A: Yes. The 2911 supports an external redundant power supply, which can provide redundancy or PoE boost. An optional DC-PoE power supply is also available.

Q: How many service modules can the 2911 chassis hold?
A: The chassis takes up to two SRE modules, one ISM-type SRE 300 and one service module type SRE 700, 710, 900 or 910.

Q: Can I add WAN or voice interfaces later?
A: Yes. The four EHWIC slots accept EHWICs and HWICs, and the two onboard DSP slots take PVDM modules for voice.
