Cisco

Cisco C2911-VSEC-SRE-K9 | ISR 2911 Router, 3x 1G, UC+SEC, SRE 300, PVDM3-16

C2911-VSEC-SRE-K9

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Cisco ISR 2911 is a branch-office router from the 2900 Series Integrated Services Routers (ISR G2). It combines routing, voice, security and on-router application hosting in a single 2RU chassis, making it suited to branch sites that need secure WAN and VPN connectivity alongside survivable telephony.

This bundle is defined by its UC and SEC licence PAKs, an SRE 300 Services-Ready Engine module and a PVDM3-16 DSP. It provides three onboard 10/100/1000 RJ-45 WAN ports, four EHWIC slots (two double-wide), one service module slot for the SRE 300, one ISM slot and two onboard PVDM slots. Memory is 512 MB DDR2 ECC DRAM by default, expandable to 2 GB, with 256 MB of external Compact Flash by default, expandable to 4 GB. Embedded hardware-based encryption acceleration supports IPSec VPN, and the router can handle up to 50 Cisco Unified SRST or CCME sessions.

The chassis supports EHWIC, HWIC, VIC and VWIC modules, PVDM3 DSP modules and service modules. AC, PoE and DC power supply options are offered across the platform, and the external Cisco RPS 2300 can provide redundant power or PoE boost. It mounts in a 19 inch rack or on a wall.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Multi-core processor architecture with embedded IPSec VPN hardware acceleration
- Multigigabit Fabric (MGF) for module-to-module communication
- TDM interconnect fabric for scaling DS-0 channel capacity in voice deployments
- SRE 300 module hosts Cisco, third-party and custom applications independently of the router CPU
- SRST and CCME survivable telephony for branch voice
- USB console access alongside serial console and aux ports
- External Cisco RPS 2300 supported for redundancy or PoE boost
- NEBS-designed chassis with optional fan filter and front-to-back airflow kit

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Onboard WAN ports: 3 x 10/100/1000 RJ-45
- EHWIC slots: 4 (2 double-wide)
- Service module slots: 1 (SRE 300 ISM)
- ISM slots: 1
- Onboard DSP (PVDM) slots: 2 (PVDM3-16 in this bundle)
- DRAM: 512 MB DDR2 ECC default, 2 GB maximum
- External Compact Flash: 256 MB default, 4 GB maximum
- USB 2.0 Type A slots: 2
- Console ports: 1 x USB Type B, 1 x serial, 1 x serial auxiliary
- Cisco Unified SRST sessions: 50
- Cisco Unified CCME sessions: 50
- Hardware-based encryption acceleration: Yes
- Power supply options: AC, PoE and DC
- AC input: 100 to 240 VAC, 47 to 63 Hz
- Typical power with no modules: 50 W
- Maximum power with AC power supply: 210 W
- Dimensions (H x W x D): 88.9 x 438.2 x 304.8 mm
- Rack height: 2RU, 19 inch mount, 23 inch optional
- Weight with AC power supply (no modules): 8.2 kg
- Operating temperature (up to 1,800 m): 0 to 40 C
- Operating relative humidity: 5 to 85%

FAQs

Q: Which licences come with this bundle?
A: It includes the Unified Communications (UC) and Security (SEC) technology package licence PAKs on the Universal IOS image. The Data licence (SL-29-DATA-K9) is a separate option.

Q: What does the SRE 300 module do?
A: The SRE 300 (ISM-SRE-300-K9) is a Services-Ready Engine that runs in the service module slot. It hosts Cisco, third-party and custom applications independently of the router CPU.

Q: What power options does the 2911 platform support?
A: The 2911 platform supports AC, PoE and DC power supplies. The AC supply accepts 100 to 240 VAC at 47 to 63 Hz with a 210 W maximum platform draw. An external Cisco RPS 2300 can provide redundant power or PoE boost.

Q: Which interface modules can be fitted?
A: It accepts EHWIC, HWIC, VIC and VWIC modules, PVDM3 DSP modules and service modules. There are four EHWIC slots, two of which can take double-wide modules.

Q: How many SRST or CCME sessions are supported?
A: The platform supports up to 50 Cisco Unified SRST sessions and up to 50 Cisco Unified CCME sessions.
