• Cisco Nexus 9018 switch in ASR-9902-FC 2RU chassis with gigabit ports
1 1

Cisco

Cisco ASR-9902-FC | ASR 9902 2RU Router, 800G, Flexible Consumption

ASR-9902-FC

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The ASR 9902 is a compact 2RU Cisco IOS XR aggregation router that delivers up to 800 Gbps of nonblocking full-duplex capacity. This ASR-9902-FC is the Flexible Consumption Model chassis, aimed at business PE, metro aggregation, internet peering, Data Center Interconnect, BNG and mobile edge deployments in 4G and 5G networks.

Port density is 2 QSFP-DD and 6 QSFP28 ports (10/40/100GbE), 16 SFP28 dual-rate ports (10/25GbE) and 24 SFP+ ports (10GbE LAN or WAN OTN), with MACsec supported on all ports. The chassis has two redundant Route Processors, an integrated switch fabric and three redundant fans, and takes up to two 1.6 kW AC or DC power modules in 1+1 redundancy. AC and DC modules cannot be mixed. The Route Processor carries 32GB of DDR4 memory.

As a Flexible Consumption SKU, software is licensed per capacity through RTU licences (Edge Essentials or Edge Advantage) with a software subscription, rather than the separate feature licences used by the traditional ASR-9902. Related parts include the A99-RP-F-FC route processor, PWR-1.6KW-AC and PWR-1.6KW-DC power modules and the ASR-9902-FAN.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Runs the same Cisco IOS XR software image as other ASR 9000 Series routers
- Mix and match 10/25/40/100GbE interface types on one chassis
- DWDM support via OTN (ITU-T G.709) with FEC
- Hardware-based IEEE 1588 timing, GPS and BITS interfaces, SyncE and PTP Telecom profiles
- Carrier-class OAM including NetFlow, 802.1ag, 802.3ah, Y.1731, IP SLA and VCCV
- Fully redundant design with 2 route processors, 2 power supplies and 3 fans
- Compact 19 in. depth with front-to-back airflow, suited to mobile edge in 4G and 5G networks
- Route Processor with 64-bit Intel CPU, console, aux, 2 management Ethernet, USB, GPS and 2 BITS interfaces

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Form factor: 2RU compact chassis
- Capacity: up to 800 Gbps nonblocking full-duplex
- QSFP-DD ports: 2 x (10/40/100GbE)
- QSFP28 ports: 6 x (10/40/100GbE)
- SFP28 ports: 16 x dual-rate (10/25GbE)
- SFP+ ports: 24 x (10GbE LAN / WAN OTN)
- Security: MACsec support on all ports
- Redundancy: route processor, power supply, fan and software
- Route Processors: 2 redundant, integrated switch fabric
- Fans: 3 redundant, front-to-back airflow
- Power: up to 2 x 1.6 kW AC or DC modules, 1+1 redundancy, AC and DC cannot be mixed
- RP memory: 32GB DDR4 SDRAM
- Operating system: Cisco IOS XR (64-bit)
- Dimensions (H x W x D): 87.63 x 439.74 x 482.60 mm
- Weight (fully populated): 21.04 kg
- Rack mounting: 2-post and 4-post, 19-in. and 23-in.
- Operating temperature: 5 to 40 C
- Operating humidity: 10 to 85% RH
- Storage temperature: -40 to 70 C
- Operating altitude: 0 to 4000 m
- Ethernet standards: IEEE 802.3ae, 802.3by, 802.3cc, 802.3ba
- Compliance: NEBS Level 3, FCC Class A, AS/NZS 3548 Class A

FAQs

Q: How is this Flexible Consumption SKU licensed?
A: Software is licensed per capacity through RTU licences, Edge Essentials or Edge Advantage in 100G or 400G increments, together with a software subscription. The FC route processor is A99-RP-F-FC.

Q: How does ASR-9902-FC differ from the traditional ASR-9902?
A: The ASR-9902-FC is ordered under the Cisco IOS XR Flexible Consumption Model with pay-as-you-grow capacity licensing. The traditional ASR-9902 uses separate feature licences instead.

Q: What power supplies does the ASR 9902 take?
A: It takes up to two 1.6 kW modules, PWR-1.6KW-AC or PWR-1.6KW-DC, in 1+1 redundancy. AC and DC modules cannot be mixed in the same chassis.

Q: Which port types and speeds does it support?
A: It has 2 QSFP-DD and 6 QSFP28 ports at 10/40/100GbE, 16 SFP28 ports at 10/25GbE and 24 SFP+ ports at 10GbE. 1GE is supported via smart SFP or nV Satellite.

Q: Which optics can I use?
A: Pluggable optics are shared with the ASR 9000 modular and compact chassis. Check the Cisco Optics Compatibility Matrix at tmgmatrix.cisco.com for supported part numbers.
