• Cisco ASR-9902 2RU router chassis with Nexus 9018 switch ports
1 1

Cisco

Cisco ASR-9902 | ASR 9902 Router, 2RU, 800G, Traditional Business Model

ASR-9902

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The ASR 9902 is a compact 2RU router in the ASR 9000 Series, built for service provider and enterprise edge roles. It delivers up to 800 Gbps of nonblocking capacity and runs Cisco IOS XR, the same software image used across the wider ASR 9000 family. Typical deployments include business PE, metro aggregation, cloud edge, internet peering, Data Center Interconnect, BNG and 4G/5G mobile edge.

The fixed port layout provides 2 QSFP-DD and 6 QSFP28 ports supporting 10/40/100GbE, 16 dual-rate SFP28 ports for 10/25GbE, and 24 SFP+ ports for 10GbE LAN or WAN OTN. The chassis has dual redundant route processors with 32GB DDR4 memory, three redundant front-to-back fans, and bays for two 1.6 kW hot-swap power modules in 1+1 redundancy. MACsec is available on all ports. This SKU is the Traditional Business Model chassis, which is separate from the ASR-9902-FC Flexible Consumption chassis.

Power modules are PWR-1.6KW-AC or PWR-1.6KW-DC, and AC and DC modules cannot be mixed in one chassis. Optics are shared with the ASR 9000 modular and compact chassis, and hardware timing support covers IEEE 1588, SyncE and GPS/BITS for mobile edge synchronisation.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Multi-rate ports allow 10, 25, 40 and 100 Gigabit Ethernet on one chassis
- DWDM support via OTN (ITU-T G.709) with FEC
- Carrier-class OAM including NetFlow, 802.1ag, 802.3ah, Y.1731, IP SLA and VCCV
- Hardware-based IEEE 1588, SyncE and GPS/BITS interfaces for 4G/5G mobile edge timing
- Fully redundant design with 2 route processors, 2 power supplies and 3 fans
- MACsec on all ports
- Runs the same IOS XR image as other ASR 9000 platforms
- Rack mounting options for 2-post and 4-post, 19-in. and 23-in. racks

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Form factor: 2RU
- Switching capacity: up to 800 Gbps nonblocking, full duplex
- QSFP-DD ports: 2 x 10/40/100GbE
- QSFP28 ports: 6 x 10/40/100GbE
- SFP28 ports: 16 x dual-rate 10/25GbE
- SFP+ ports: 24 x 10GbE LAN / WAN OTN
- Route processors: dual redundant, 64-bit Intel CPU, 32GB DDR4 SDRAM
- Power: up to 2 x 1.6 kW AC or DC hot-swap modules, 1+1 redundancy
- Cooling: 3 redundant fans, front-to-back airflow
- Dimensions (H x W x D): 3.45 x 17.3 x 19 in. (87.63 x 439.74 x 482.60 mm)
- Weight (fully populated): 46.39 lb (21.04 kg)
- Rack mounting: 2-post and 4-post, 19-in. and 23-in.
- Front panel RP interfaces: console, aux, 2 management Ethernet, USB, GPS, 2 BITS
- Timing: IEEE 1588, G.8265.1, G.8275.1, G.8275.2, SyncE, GPS/BITS
- Operating temperature: 5 to 40 C (41 to 104 F)
- Operating humidity: 10 to 85% RH
- Operating altitude: 0 to 4000 m
- Storage temperature: -40 to 70 C (-40 to 158 F)
- Compliance: NEBS SR-3580 Level 3, FCC Class A, AS/NZS 3548 Class A, AS/NZS 60950

FAQs

Q: What is the difference between ASR-9902 and ASR-9902-FC?
A: ASR-9902 is the Traditional Business Model chassis. ASR-9902-FC is the Flexible Consumption chassis, which uses Essentials, Advantage and Premier software tiers licensed per 100G/400G.

Q: What software and licensing does the ASR-9902 use?
A: It runs Cisco IOS XR. Optional Smart or RTU licences cover features such as VRFs, CGN, advanced optics, mobile, lawful intercept and nV satellite clients.

Q: Which power modules does it take?
A: It takes up to two 1.6 kW hot-swap modules, either PWR-1.6KW-AC or PWR-1.6KW-DC, in 1+1 redundancy. AC and DC modules cannot be mixed in the same chassis.

Q: Which optics are supported?
A: Pluggable optics are shared with the ASR 9000 modular and compact chassis. Check the Cisco Optics Compatibility Matrix for the exact part numbers supported on each port type.

Q: Can it support 1GE connections?
A: Yes, 1GE is supported through a smart SFP or via nV Satellite.

Q: Does it support timing for mobile networks?
A: Yes. It provides hardware-based IEEE 1588, PTP telecom profiles, SyncE and GPS/BITS interfaces for 4G/5G mobile edge timing.
