• Cisco ASR-920-10SZ-PD white gray router with 10x 1G SFP and 2x 10G SFP+ ports
1 1

Cisco

Cisco ASR-920-10SZ-PD | ASR 920 Router, 10x 1G SFP, 2x 10G SFP+, PD

ASR-920-10SZ-PD

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The ASR 920 Series is a compact 1RU Carrier Ethernet and converged access router built for mobile backhaul, Metro Ethernet and business services. This PD variant is suited to small aggregation sites and sealed or ETSI-depth cabinets where a temperature-hardened platform is needed.

It provides 10x 1GE SFP access ports and 2x 10GE SFP+ uplink ports, running Cisco IOS XE. The platform supports MPLS with L2VPN, L3VPN, VPLS and H-VPLS, hierarchical QoS with eight queues per service, and Carrier Ethernet OAM. Timing is handled by integrated BITS, 1PPS and ToD interfaces with SyncE and IEEE-1588 support. Ports and features are activated through Cisco's pay-as-you-grow licensing model, and the operating range extends from -40 C to +70 C depending on altitude and optics.

The router accepts a wide range of Cisco FE, GE and 10G SFP and SFP+ optics, including extended-temperature, BiDi, CWDM and DWDM modules and SFP-H10GB-CUxM direct-attach cables. Optional ETSI, 19-inch and 23-inch rack-mount kits are available, and the platform can be managed with Cisco Prime for EPN.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- MPLS in the access layer with L2VPN, L3VPN, VPLS and H-VPLS support
- Hierarchical QoS with eight queues per service and three levels of scheduling
- Integrated BITS, 1PPS and ToD timing with SyncE (ESMC/SSM) and IEEE-1588
- Carrier Ethernet OAM including Layer 2 CFM, IP SLA and MPLS OAM
- Dying gasp and four external alarm inputs for remote site monitoring
- Pay-as-you-grow licensing to activate additional ports and features on demand
- Extended temperature range suited to outdoor sealed cabinets and ETSI 300 mm deep cabinets
- Managed with Cisco Prime for EPN

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Access ports: 10x 1GE SFP
- Uplink ports: 2x 10GE SFP+
- Form factor: 1RU, temperature-hardened compact chassis
- Software: Cisco IOS XE
- Power supplies: 2 built-in redundant supplies (AC or DC across the ASR 920 family)
- Airflow: Front-to-back
- Timing: Integrated BITS, 1PPS and ToD interfaces, SyncE and IEEE-1588
- Operating temperature: -40 C to +70 C up to 300 m altitude
- Operating temperature: -40 C to +65 C up to 1,800 m altitude
- Operating temperature: -40 C to +55 C up to 4,000 m altitude
- Relative humidity: 5 to 95 percent, non-condensing
- Rack mounts: ETSI, 19-inch and 23-inch kits (optional)
- Seismic rating: Zone 4
- NEBS: GR-63-CORE Issue 4, GR-1089-CORE Issue 6, SR-3580 Level 4
- EMC: FCC Part 15 Class A, EN55022 Class A, CISPR22 Class A
- Safety: UL 60950-1, IEC 60950-1, EN 60950-1, AS/NZS 60950.1

FAQs

Q: How are additional ports and features enabled?
A: The ASR 920 platform uses Cisco pay-as-you-grow licensing to activate extra 1G and 10G ports and features such as MPLS on demand.

Q: What optics does it work with?
A: It supports a wide range of Cisco FE and GE SFP modules (SX, LX, ZX, BX, CWDM, DWDM, rugged) and 10G SFP+ modules (SFP-10G-SR, LR, ER, ZR, LRM, BiDi, DWDM, CWDM), plus SFP-H10GB-CUxM direct-attach cables.

Q: How is it powered?
A: The ASR 920 family uses dual redundant built-in power supplies. AC models accept 85 to 264V AC, and DC models accept -19.2 to -72V DC.

Q: Which rack-mount options are available?
A: ETSI, 19-inch and 23-inch rack-mount kits are available as optional accessories, including compact A920-RCKMT-C versions.

Q: What is it typically used for?
A: It is typically deployed for mobile backhaul and RAN aggregation, Metro Ethernet access, business services with 10GE UNI, and small aggregation sites or outdoor cabinets.
