• Cisco Catalyst 9300 switch with Gigabit ports and silver finish
1 1

Cisco

Cisco ASR-907 | ASR 900 Series 907 Modular Router Chassis, 7RU, 16 Slots

ASR-907

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The ASR 907 is a seven-rack-unit, fully modular aggregation router chassis from the Cisco ASR 900 Series. It is built for service provider aggregation and remote Point-of-Presence deployments, including mobile backhaul and L2VPN and L3VPN service delivery.

The chassis provides two Route Switch Processor slots for in-box redundancy, sixteen single-width interface module slots (slots 0-15) and a single fan tray position. It supports up to three hot-swappable 1200 W power supplies in AC or DC. This SKU is the chassis only, so the RSP, power supplies and fan tray are selected separately to suit the deployment. With the RSP3C-400-W in oversubscribed mode, example I/O configurations include 16x10G plus 2x100G plus 80x1G, or 48x10G. It is rated for operation from -40 C to 65 C when fitted with industrial temperature optics.

Compatible components include the A900-RSP3C-400-W route switch processor, the A907-FAN-E enhanced fan tray, the A900-PWR1200-D DC power supply and interface modules such as the A900-IMA48D-C and A900-IMA48T-C CEM modules. An optional A900-CM-GNSS module is available for timing.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Fully modular design with online insertion and removal of all components
- In-box hardware redundancy with dual RSP slots and redundant power supplies
- Flexible I/O through 16 hot-pluggable single-width interface modules
- Supports Layer 2 VPN (L2VPN) and Layer 3 VPN (L3VPN) services
- Network timing interfaces on the RSP: BITS, 1 PPS, 2.048/10 MHz and ToD
- Proactive diagnostics including Generic Online Diagnostics (GOLD)
- Airflow baffle for front-to-back cooling
- Optional GNSS module (A900-CM-GNSS) for timing

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Chassis height: 7 RU
- Dimensions (H x W x D): 12.224 x 17.426 x 9.33 in (approx. 310.5 x 442.6 x 237 mm)
- Dimensions with FRUs (H x W x D): 12.224 x 17.426 x 10.705 in
- Weight, chassis with backplane: 15.868 kg
- RSP slots: 2
- Interface module slots: 16 (single width)
- Fan tray: 1 x A907-FAN-E enhanced fan tray with filter slot
- Power supplies: up to 3, 1200 W each (AC or DC)
- DC PSU part number: A900-PWR1200-D; input -48 V, min -40.8 VDC, max -72 VDC; output +12 VDC
- Example I/O with RSP3-400-W (oversubscribed mode): 16x10G + 2x100G + 80x1G, or 48x10G
- Operating temperature: -40 to 65 C at 1800 m (with industrial temperature optics)
- Non-operating (storage) temperature: -40 to 70 C
- Operating humidity: 5-95% non-condensing
- Operating altitude: -60 to 1800 m for full temperature range; up to 4000 m at up to 40 C
- Non-operating altitude: -60 to 4570 m
- Operating vibration: 1.0 g, 1.0 to 150 Hz
- Shock: 30 G half sine, 6 ms and 11 ms
- Operating acoustics: < 76 dBA at 27 C (NEBS GR-63)
- Airflow: front-to-back with airflow baffle

FAQs

Q: Which route switch processor does the ASR 907 use?
A: The ASR 907 uses the A900-RSP3C-400-W. The ASR 907 RSP form factor differs from the ASR 902 and ASR 903, so RSPs are not shared across chassis types.

Q: How many power supplies can the chassis hold, and what type?
A: It supports up to three hot-swappable 1200 W power supplies, available in AC or DC. The DC supply is the A900-PWR1200-D, with a -48 VDC input and +12 VDC output.

Q: Which fan tray does the ASR 907 take?
A: It uses the A907-FAN-E enhanced fan tray, which includes a filter slot. Cooling is front-to-back with an airflow baffle.

Q: Which interface modules work in this chassis?
A: The ASR 907 has 16 single-width interface module slots and supports modules listed for the ASR 907 in the ASR 900 Series interface module compatibility matrix. Examples include the A900-IMA48D-C 48-port T1/E1 CEM and A900-IMA48T-C 48-port T3/E3 CEM modules.

Q: How does this SKU differ from ASR-907=?
A: This SKU is the ASR 907 chassis only, without an RSP, power supplies or fan tray. ASR-907= is the spare version of the same chassis.
