• Cisco ASR-9000V-DC-E silver switch with 44x1G ports, 4x10G uplinks, DC input
1 1

Cisco

Cisco ASR-9000V-DC-E | ASR 9000v nV Satellite, 44x 1G SFP, DC ETSI Chassis

ASR-9000V-DC-E

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The ASR 9000v is a compact, environmentally hardened, front-access extension shelf for the Cisco ASR 9000 Series. It uses nV (network virtualisation) technology to bring ASR 9000 services to access locations such as remote points of presence, cabinets and non-temperature-controlled buildings, which suits service provider and telco DC-powered environments.

This DC Power ETSI Chassis (DC-E) variant provides 44 SFP ports supporting 10, 100 and 1000 Mbps, plus 4 SFP+ 10GE pluggable ports. It has two redundant ETSI DC inputs (DC-A and DC-B) accepting -36V to -74V DC, with nominal power of 159 W and a maximum of 210 W. The chassis is rated for operation from -40 C to +65 C and is NEBS compliant to GR-1089 Issue 5 and GR-63 Issue 3. EOBC Ethernet management and Console serial ports are provided.

The shelf operates as a satellite to an ASR 9000 Series host running Cisco IOS XR, which delivers its services and features, so licensing follows the host. Pluggable SFP and SFP+ optics are listed in the Cisco Optical Pluggable Modules for ASR 9000v Data Sheet, and the front-accessed fan tray spare is ASR-9000V-FAN=.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Operates as an nV satellite of an ASR 9000 Series host, with services and features delivered by the host running IOS XR
- Managed through the host's software management infrastructure rather than as a standalone network element
- Deployable adjacent to or remotely from the host, including over DWDM
- Connects to multiple redundant ASR 9000 hosts for resiliency against shelf, access port and fabric port failures
- Environmentally hardened for cabinets and non-temperature-controlled buildings
- Fully front-access design, wall-mountable or mountable back-to-back
- Ultra-low power draw and small footprint
- Supported in the ASR 9000 Series Craft Tool (ACT) and Cisco Prime for Service Providers

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Interfaces: 44 x SFP ports (10, 100 and 1000 Mbps)
- Interfaces: 4 x SFP+ 10GE pluggable ports
- Power inputs: ETSI DC-A and DC-B, two redundant DC inputs
- DC input voltage: -36V to -74V DC
- Power: nominal 159 W, maximum 210 W
- Management ports: EOBC Ethernet management port and Console serial port
- Time of day (ToD) / PPS: reserved for future use
- Dimensions (H x W x D): 3.96 x 44.24 x 23.10 cm (1.560 x 17.417 x 9.095 in)
- Weight: 4.22 kg (9.30 lbs)
- NEBS: GR-1089 Issue 5 and GR-63 Issue 3
- Operating temperature: -40 to +65 C
- Operating humidity: 5-85% noncondensing, up to 95% noncondensing guaranteed
- Storage temperature: -40 to +70 C
- Storage humidity: 93% noncondensing
- Operating altitude: 4000 m (13,123 ft)
- Field-replaceable parts: front-accessed fan tray (ASR-9000V-FAN=) and filter

FAQs

Q: Does the ASR 9000v need its own licence?
A: No separate licence is listed for the shelf. Features and services come from the ASR 9000 Series host running Cisco IOS XR, so licensing follows the host.

Q: Can it be used as a standalone router?
A: No. It operates as an nV satellite and must be connected to an ASR 9000 Series host, which provides its services and management.

Q: What power does the DC-E chassis use?
A: It has two redundant ETSI DC inputs, DC-A and DC-B, accepting -36V to -74V DC. Nominal draw is 159 W with a maximum of 210 W.

Q: Which optics does it use?
A: The 44 SFP ports and 4 SFP+ ports take pluggable optics listed in the Cisco Optical Pluggable Modules for ASR 9000v Data Sheet.

Q: How does this SKU differ from the ASR 9000v-V2?
A: This is the original ASR 9000v DC ETSI chassis (DC-E). The ASR 9000v-V2 (A9KV-V2-DC-E) is a different SKU and requires IOS-XR 5.2.2 or later.
