• Cisco 8011-4G24Y4H-I with silver server rack, black accents, glass front
1 1

Cisco

Cisco 8011-4G24Y4H-I | 8010 24x 25G SFP28, 4x 100G QSFP28 I-Temp Router

8011-4G24Y4H-I

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Cisco 8010 series 8011-4G24Y4H-I is a 1RU fixed, industrial-temperature router built for service-provider cell-site routing, access and aggregation. It suits mobile backhaul deployments, including IP65/IP66 outdoor cabinets with a heat exchanger, where extended temperatures and precise timing matter. It runs Cisco IOS XR and can also operate as a satellite port extender for ASR 9000 5th-generation systems.

Front-panel connectivity is 4x 40/100G QSFP28 ports, 24x 1/10/25G SFP28 ports and 4x 10/100/1000M RJ-45 copper ports. The 100G ports can also run as 4x25G or 4x10G. Forwarding performance reaches up to 480 Mpps, backed by a 4-core 2.2GHz CPU, 16GB DRAM and 38GB eMMC. The I-Temp rating covers -40 to +65 C operation, and airflow is front to back through five fixed redundant fans.

Power comes from modular redundant AC or DC power modules, with Cisco modelling consumption at about 150 W. Cisco IOS XR software licensing applies under the Flexible Consumption Model 2.0. It works with 1/10/25G SFP, SFP+ and SFP28 optics and 40/100G QSFP+ and QSFP28 optics, and supports the 8000-TIC and 8000-TIC-GNSS timing cards.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Runs Cisco IOS XR under the Flexible Consumption Model 2.0
- Designed for cell-site and aggregation deployments, including IP65/IP66 outdoor cabinets with a heat exchanger (GR487)
- Can operate as a satellite port extender for ASR 9000 5th-generation systems (IOS XR 26.2.1 minimum)
- Optional GNSS-based PRTC-B timing card for network synchronisation
- Redundant hot-swappable AC or DC power modules
- Redundant fixed fans for continuous cooling
- Flexible 100G ports supporting 40G, 4x25G and 4x10G modes

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Chassis product ID: 8011-4G24Y4H-I
- QSFP28 ports: 4 x 40/100G
- SFP28 ports: 24 x 1/10/25G
- Copper ports: 4 x 10/100/1000M RJ-45
- 100G port speeds (ports 0-3): 4x25G, 40G, 4x10G
- Performance: up to 480 Mpps
- CPU: 4 cores 2.2GHz
- Memory: 16GB DRAM
- Storage: 38GB eMMC
- Power supplies: modular redundant AC/DC
- Fans: 5 fixed fans with redundancy
- Airflow: front to back
- Operating temperature: -40 to +65 C (I-Temp)
- Storage temperature: -40 to +70 C
- Height: 43.6 mm (1.72 in.), 1RU
- Width: 439.4 mm (17.3 in.)
- Depth: 260 mm (10.24 in.)
- Weight: 4.5 kg without PSU, 5.7 kg with 2 PSUs
- Modelled power: 150 W
- NEBS: GR-63-CORE, GR-1089-CORE, GR-3108 Class-2
- ATIS TEER certification: ATIS-0600015.03.2009
- Timing: 8000-TIC card (10MHz, 1PPS, ToD, BITS)
- Management: 1G Ethernet management port, USB console, USB memory port, RS232 console, alarm port

FAQs

Q: Does this router need a software licence?
A: Yes. Cisco IOS XR software licensing applies, sold under the Flexible Consumption Model 2.0 with Essentials, Advantage and Premier tiers per device.

Q: How is this router powered?
A: It uses modular redundant AC or DC power modules, with Cisco modelling consumption at about 150 W.

Q: Which optics does it support?
A: It supports 1/10/25G SFP, SFP+ and SFP28 optics and 40/100G QSFP+ and QSFP28 optics. The 100G ports can also run as 4x25G or 4x10G.

Q: Can it provide precise network timing?
A: Yes. It supports the 8000-TIC timing card (10MHz, 1PPS, ToD, BITS) and the optional 8000-TIC-GNSS card with a PRTC-B GNSS receiver.

Q: How does it differ from the 8011-32Y8L2H2FH?
A: This model has 4x 100G QSFP28, 24x 1/10/25G SFP28 and 4x 1G copper ports in an industrial-temperature (I-Temp) design, while the 8011-32Y8L2H2FH uses 2x400G, 2x100G and 8x10/25/50G ports in a commercial-temperature (C-Temp) design.
