Aruba JL429A | 3810M 48-Port Gigabit PoE+ Switch, 1050W, 4x 10G SFP+
SKU:JL429A
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The Aruba 3810M is a 1U stackable, managed Layer 3 switch built for enterprise, SMB and branch office access networks. It suits sites that need to power access points, IP phones and IoT devices over PoE+ while keeping 10GbE uplinks and resilient stacking available.
This model provides 48 x 10/100/1000 RJ-45 PoE+ ports and 4 x 10GbE SFP+ ports through the JL083A module. Switching capacity is 320 Gbps with a forwarding rate of up to 190.5 Mpps. A 1050W Aruba X372 54VDC hot-swappable power supply is installed, and a second supply can be added for 1+1 redundancy and higher PoE+ capacity. The chassis has one expansion module slot and one stacking module slot, and the advanced Layer 2 and Layer 3 feature set needs no software licence.
The switch can be managed with Aruba AirWave or Aruba Central, and it integrates with Aruba ClearPass for centralised security and captive portal services.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Advanced Layer 2 and Layer 3 feature set including OSPF, IPv6, IPv4 BGP, Dynamic Segmentation, QoS and policy-based routing
- No software licence required for the advanced feature set
- Backplane stacking with redundant, hot-swappable power supplies in a 1U form factor
- OpenFlow support for SDN applications
- Managed with Aruba AirWave or Aruba Central
- Aruba ClearPass integration for centralised security and captive portal
- Aruba ProVision ASIC for performance and programmability
- Full PoE+ provisioning on all 48 ports with sufficient power supply capacity
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Device type: Layer 3 managed, stackable switch
- Enclosure: 1U rack-mountable
- Ports: 48 x 10/100/1000 RJ-45 PoE+
- Uplink ports: 4 x 10GbE SFP+ (JL083A module)
- Expansion slots: 1 x expansion module slot, 1 x stacking module slot
- Switching capacity: 320 Gbps
- Forwarding rate: up to 190.5 Mpps (64-byte packets)
- Latency (1000Base-T): 2.8 µs
- Latency (10 Gbps): 1.8 µs
- Latency (40 Gbps): 1.5 µs
- Processor: 1 GHz ARM Cortex A9 dual-core
- RAM: 6 GB DDR3 SDRAM
- Flash memory: 1 GB
- Power supply: 1 x Aruba X372 54VDC 1050W hot-swappable (2 maximum)
- Power redundancy: 1+1 with optional second power supply
- Maximum PoE+ power: up to 1440W
- Included modules: Aruba 3810 Switch Fan Tray (JL088A), Aruba 3810M 4SFP+ Module (JL083A)
- Management protocols: SNMP 1/2c/3, RMON, Telnet, SSH, HTTP, CLI
- Standards: IEEE 802.3, 802.3u, 802.3ab, 802.3af, 802.3at, 802.3ad (LACP), 802.1p, 802.1Q, 802.1s, 802.1v, 802.1X, 802.1AB (LLDP)
FAQs
Q: Does the 3810M need a software licence?
A: No. The advanced Layer 2 and Layer 3 feature set, including OSPF, IPv6 and IPv4 BGP, is included without a separate software licence.
Q: Can all 48 ports deliver PoE+ at the same time?
A: The installed 1050W power supply covers a large share of the PoE+ load. Adding a second supply raises PoE+ support to up to 1440W, which is needed to provision full PoE+ on all 48 ports.
Q: What power supply does this switch use?
A: It uses the Aruba X372 54VDC 1050W hot-swappable power supply, and one is installed. A second supply can be added for 1+1 redundancy.
Q: Can this switch be stacked?
A: Yes. It has one stacking module slot for a 3810M stacking module, enabling backplane stacking with other 3810M switches.
Q: How is the switch managed?
A: It can be managed through the CLI, SSH, Telnet, HTTP and SNMP, as well as Aruba AirWave or Aruba Central. It also integrates with Aruba ClearPass.
