Arista CCS-710XP-12TH-2S | 710XP 12-Port Gigabit PoE+ Fanless Switch, 150W, 2x 10G SFP+
SKU:CCS-710XP-12TH-2S
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The Arista 710XP is a compact, fanless campus-edge PoE switch built for space-constrained and noise-sensitive locations such as conference rooms, retail areas, classrooms and broadcast control booths. It runs Arista EOS and can be managed on-premises or through CloudVision, including CloudVision CUE and CloudVision-as-a-Service.
This 12-port variant provides 8 x 10M-1GbE RJ45 ports at 30W (802.3af/at) and 4 x 10M-1GbE RJ45 ports at 60W (802.3bt), sharing a 150W PoE budget. Two 1/10G SFP+ uplinks handle aggregation. A single 180W fixed internal AC power supply feeds the unit, and there are no fans. Switching ASIC capacity is 208 Gbps with 64 Gbps throughput and 95 Mpps forwarding, with Layer 3 routing including OSPF, BGP, IS-IS and RIPv2.
The SFP+ ports accept 1G and 10G optics and cables, from 10GBASE-CR and AOC through SR, LR and ER. Optional mounting kits cover magnet, DIN-rail and 19-inch rack installs. The switch belongs to EOS licence group G0 and requires EOS 4.35.0 or later.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Fanless, silent operation for noise-sensitive spaces
- Optional magnet, L-bracket, 19-inch rack and DIN-rail mounting
- Cognitive Continuous PoE keeps powered devices running during a switch reboot
- Secureboot with Hardware Root of Trust
- Zero Touch Provisioning
- On-premises or cloud management via CloudVision
- Layer 3 routing with OSPF, BGP, IS-IS, BFD, VRF and policy-based routing
- 802.1X, MAC-based authentication and dynamic VLAN assignment
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Ports: 12 RJ45, 2 x 1/10G SFP+
- 10M-1G PoE ports (802.3af/at, 30W): 8
- 10M-1G PoE ports (802.3bt, 60W): 4
- PoE power budget: 150W
- Switching ASIC capacity: 208 Gbps (ingress + egress)
- Throughput (FDX): 64 Gbps
- Packet forwarding: 95 Mpps
- Latency (RJ-45): 1.8 microseconds
- CPU: Quad Core ARM
- System memory: 8 GB
- System flash: 20 GB
- Packet buffer: 1.5 MB
- USB ports: 1
- Console ports: 1
- Power supply: 180W fixed internal AC (single)
- Input voltage: 100-240VAC, 50-60Hz
- Input connector: IEC 320-C13
- Maximum power draw, excluding PoE: 30W
- Fans: None
- Dimensions (WxHxD): 26.9 x 4.4 x 25.4 cm (10.6 x 1.75 x 10 in)
- Operating temperature: 0 to 40 C
- Storage temperature: -40 to 70 C
- Relative humidity: 5 to 90%
- Operating altitude: 0 to 3,000 m
- MAC address table: 16K
- Minimum EOS: 4.35.0
FAQs
Q: How is the 150W PoE budget shared across the ports?
A: The 150W budget is shared across all 12 RJ45 ports. Eight ports support 802.3af/at up to 30W and four ports support 802.3bt up to 60W, so the total available PoE is the 150W budget rather than the sum of the port maximums.
Q: Does this switch need a licence or subscription?
A: It runs Arista EOS and belongs to EOS licence group G0 (LIC-FIX) and CloudVision licence group G0. The optional LIC-FIX-G0-FLX-L (FLX-Lite) licence adds full routing up to 8K routes, and CloudVision subscriptions are optional.
Q: Which optics and cables work in the SFP+ ports?
A: The two SFP+ ports support 1G and 10G optics and cables. Supported 10G types include 10GBASE-CR (0.5-5m), AOC (3-30m), SRL (100m), SR (300m), LRL (1km), LR (10km) and ER (40km).
Q: What mounting options are available?
A: Optional kits cover the accessory kit (KIT-CCS-710), DIN rail (KIT-CCS-710-DIN), 19-inch rack mount (KIT-CCS-710XP-12-RM) and magnet mount (KIT-CCS-710XP-MGN).
Q: What power connection does it use?
A: It has a single fixed internal 180W AC power supply with an IEC C13 inlet, accepting 100-240VAC at 50/60Hz.
