• Meraki MR76-HW outdoor Wi-Fi 6 access point with white body and three antennas
1 1

Meraki

Meraki MR76-HW | MR76 Wi-Fi 6 Outdoor Access Point, 1.7 Gbps, IP67

MR76-HW

POA
POA
POA
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

The Meraki MR76-HW is a rugged cloud-managed Wi-Fi 6 outdoor access point designed for harsh outdoor and industrial environments. With its IP67 rating, this 2x2:2 MU-MIMO access point delivers up to 1.7 Gbps aggregate throughput across dual-band 2.4 GHz and 5 GHz radios. Featuring four dedicated radios including WIDS/WIPS security scanning and Bluetooth Low Energy, the MR76 provides enterprise-grade performance with cloud-based management and automatic RF optimization for outdoor campuses, warehouses, and industrial deployments.

Features

Wi-Fi 6 (802.11ax) with OFDMA and MU-MIMO for high-density environments
- Four integrated radios: 2.4 GHz, 5 GHz, dedicated WIDS/WIPS, and Bluetooth LE
- Dedicated scanning radio for real-time wireless security and RF analytics
- Integrated Bluetooth Low Energy for beaconing and location services
- Cloud-managed with automatic firmware updates and zero-touch provisioning
- Automatic RF optimization for channel selection and transmit power
- Transmit beamforming and enhanced receive sensitivity for extended range
- Self-configuring mesh networking with auto-healing capabilities
- Layer 7 packet inspection and application-aware traffic shaping
- Enterprise security with AES encryption, 802.1X, and Active Directory integration
- Built-in wireless intrusion detection and prevention (WIDS/WIPS)
- Guest access with customizable captive portal and splash pages
- Voice and video optimizations with QoS support
- Remote diagnostic tools and 24/7 cloud monitoring
- PCI compliance reporting for retail deployments
- IP67-rated ruggedized design for outdoor and industrial use

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

Wireless Standard: Wi-Fi 6 (802.11ax)
- Radio Configuration: 2x2:2 MU-MIMO, dual-band 2.4 GHz and 5 GHz
- Maximum Aggregate Data Rate: 1.7 Gbps (up to 1,201 Mbps on 5 GHz, 286 Mbps on 2.4 GHz)
- Additional Radios: Dedicated dual-band WIDS/WIPS radio, integrated Bluetooth Low Energy radio
- Ethernet Port: 1x Gigabit Ethernet (10/100/1000 BASE-T)
- Power: 802.3af PoE, 15W maximum
- Antenna Type: External N-type connectors (antennas sold separately)
- Environmental Rating: IP67 rated for dust and water resistance
- Operating Temperature: -40°C to 65°C (-40°F to 149°F)
- Dimensions: 30.0 cm x 15.3 cm x 5.5 cm (11.81 in x 6.02 in x 2.16 in)
- Weight: Approximately 1.4 kg (3.0 lb)
- Standards: 802.11a/b/g/n/ac/ax, 802.11e/h/i/k/r/u
- Management: 100% cloud-managed via Meraki Dashboard
- Mounting: Pole and wall mount (mounting hardware included)

FAQs

Q: Does the MR76-HW come with antennas?
A: No, the MR76-HW features external N-type antenna connectors but antennas are sold separately. Compatible antennas include MA-ANT-20 (dual-band omni), MA-ANT-21 (5 GHz sector), MA-ANT-23 (2.4 GHz sector), MA-ANT-25 (dual-band patch), and MA-ANT-27 (dual-band sector).

Q: What makes the MR76 suitable for outdoor deployment?
A: The MR76 features an IP67-rated ruggedized enclosure that protects against dust, water, shock, and vibration. It operates in extended temperatures from -40°C to 65°C, making it ideal for outdoor campuses, industrial environments, and harsh weather conditions.

Q: Does the MR76 require a wireless controller?
A: No, the MR76 is 100% cloud-managed through the Meraki Dashboard. There is no need for an on-premises wireless controller, reducing hardware costs and complexity while enabling remote management from anywhere.

Q: Is a Meraki license required to operate the MR76-HW?
A: Yes, a Meraki wireless license is required to activate and manage the MR76. Licenses are available in different tiers (Enterprise or Advanced) and subscription terms, providing cloud management, automatic updates, and advanced security features.

Q: What is the dedicated third radio used for?
A: The MR76 includes a dedicated dual-band scanning radio that provides 24/7 wireless intrusion detection and prevention (WIDS/WIPS), RF spectrum analysis, and automated RF optimization. This radio operates independently without impacting client throughput or performance.
