Aruba JZ152A | 318 Series Dual-Band Hardened Access Point, RW, Non-TAA

JZ152A

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The AP-318 from the Aruba 318 Series is a hardened dual-radio 802.11ac Wave 2 (Wi-Fi 5) access point built for harsh, weather-protected environments such as warehouses, industrial freezers, unheated indoor spaces and stadiums. It uses external RP-SMA antennas, which allows high-gain large venue antennas to be fitted, and includes an integrated Bluetooth Low Energy radio for location services and wayfinding.

The 5 GHz radio delivers 4x4:4 MU-MIMO at up to 1,733 Mbps, while the 2.4 GHz radio provides 2x2:2 at up to 300 Mbps, for an aggregate peak data rate of 2.0 Gbps. Six RP-SMA connectors serve the radios (four for 5 GHz, two for 2.4 GHz). Wired connectivity comes from one 10/100/1000BASE-T RJ-45 port powered by 802.3at PoE+, plus one 1000BASE-X SFP port. Worst-case power draw is 23 W. This JZ152A SKU is the RW (Rest of World) regulatory domain, non-TAA variant.

The AP runs in controller mode with Aruba Mobility Controllers or in controllerless Aruba Instant mode, and requires ArubaOS or InstantOS 8.3.0.0 or later. The AP-220-MNT-W1 mount kit is directly compatible, and the 270 Series mounts work when the AP-270-MNT-ADP adapter is used.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Dual-radio 802.11ac Wave 2 with Multi-User MIMO
- Built-in Bluetooth Low Energy radio for location services and wayfinding
- Advanced Cellular Coexistence (ACC) minimises interference from 3G/4G, DAS and small cell equipment
- ClientMatch for dynamic client steering and AirMatch RF optimisation
- AppRF deep packet inspection for application visibility and control
- Aruba Secure Core with TPM secure boot, wireless intrusion protection and IPsec VPN
- Dynamic Segmentation for unified wired and wireless policy
- Controller mode or controllerless Instant mode, plus mesh, air monitor and spectrum analyser modes
- Sealed connector interfaces against dust and moisture
- Aruba Activate zero-touch provisioning

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- AP type: Indoor hardened, dual radio
- 5 GHz radio: 802.11ac 4x4:4 MU-MIMO, up to 1,733 Mbps
- 2.4 GHz radio: 802.11n 2x2:2, up to 300 Mbps
- Aggregate peak data rate: 2.0 Gbps
- Channel bandwidth: HT20/40, VHT20/40/80/160
- Max conducted transmit power 2.4 GHz: +22 dBm per chain, +25 dBm aggregate
- Max conducted transmit power 5 GHz: +22 dBm per chain, +28 dBm aggregate
- Associated clients: up to 256 per radio
- BSSIDs: up to 16 per radio
- Antenna ports: 4 x RP-SMA (5 GHz), 2 x RP-SMA (2.4 GHz), external antennas
- Network interface: 1 x 10/100/1000BASE-T RJ-45, auto-sensing, MDI/MDX, 802.3az EEE
- Fibre interface: 1 x 1000BASE-X SFP port
- Bluetooth: BLE radio, up to 4 dBm transmit power
- Other interfaces: Micro USB console, reset button, multi-colour status LED, Kensington security slot
- Power: 802.3at PoE+
- Maximum power consumption: 23 W
- Dimensions (W x D x H): 150 x 222 x 75 mm
- Weight: 1.225 kg
- Operating temperature: -40 to +60 C
- Storage temperature: -40 to +70 C
- Operating humidity: 5% to 95% non-condensing
- Water and dust protection: IP55
- Regulatory model number: APIN0318
- Minimum software: ArubaOS and Aruba InstantOS 8.3.0.0
- Regional variant: RW (Rest of World), non-TAA

FAQs

Q: Does the AP-318 need a separate licence?
A: No separate licence is stated for the AP. It runs in controller mode with Aruba Mobility Controllers or in controllerless Aruba Instant mode, and requires ArubaOS or InstantOS 8.3.0.0 or later.

Q: How is the AP-318 powered?
A: It is powered by 802.3at PoE+ over its RJ-45 port, with a worst-case draw of 23 W. The PoE injector or PoE+ switch is a separate item.

Q: Does it have built-in antennas?
A: No. It uses six external RP-SMA antenna connectors, four for the 5 GHz radio and two for the 2.4 GHz radio, so suitable antennas must be fitted for both radios.

Q: Which mounts are compatible?
A: The AP-220-MNT-W1 kit mounts it directly. The 270 Series mounts (AP-270-MNT-V1, -V2, -H1, -H2) are compatible when used with the AP-270-MNT-ADP adapter.

Q: What does the RW, non-TAA designation mean for JZ152A?
A: RW means the Rest of World regulatory domain, so it suits deployments in regions covered by that domain. Non-TAA means it is not a TAA-compliant variant.
