Meraki MA-MNT-MV-20 | MV Pole Mount for MV72/MV72X, 40-80mm and 85-145mm Poles
SKU:MA-MNT-MV-20
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The MA-MNT-MV-20 is a pole-mount bracket for Meraki MV72 and MV72X smart cameras. It suits pole-mounted outdoor and perimeter surveillance, such as car parks, building exteriors and yards, where a wall or flat surface is not practical.
Two pairs of straps cover poles from 40-80 mm and from 85-145 mm in diameter, so one bracket suits a range of lamp posts and street poles. The bracket measures 163.5 mm x 107.6 mm x 34.0 mm and weighs 0.289 kg. It is a passive mechanical accessory with no power draw and needs no licence or subscription.
The mount works with MV72 and MV72X cameras. It can also be combined with the MA-MNT-MV-10 Wall-Mount Arm for MV72 when an extension gives a better field of view.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Attaches an MV72-series camera to a vertical pole
- Can be used with the MV72 wall-mount arm for an extended field of view
- Two pairs of straps cover small (40-80 mm) and large (85-145 mm) poles
- Suits outdoor and perimeter surveillance installations
- Passive mechanical accessory with no power draw
- No licence or subscription requirement
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Part number: MA-MNT-MV-20
- Product type: Camera pole mount
- Pole diameter range (small straps): 40-80 mm
- Pole diameter range (large straps): 85-145 mm
- Dimensions (L x W x D): 163.5 x 107.6 x 34.0 mm
- Weight: 0.289 kg
- Compatible cameras: MV72, MV72X
- Compatible accessory: MA-MNT-MV-10 Wall-Mount Arm for MV72
- Power: None, passive mechanical mount
- Licence: None required
FAQs
Q: Does this pole mount need a licence or subscription?
A: No. It is a passive mounting accessory and needs no licence or subscription.
Q: What pole diameters does it fit?
A: It fits poles from 40-80 mm using the small straps and from 85-145 mm using the large straps.
Q: Which Meraki cameras does it work with?
A: It is designed for MV72 and MV72X cameras.
Q: Can it be used with the MA-MNT-MV-10 wall-mount arm?
A: Yes. It can be combined with the MA-MNT-MV-10 Wall-Mount Arm for MV72 when an extension gives a better field of view.
Q: Does it need power?
A: No. It is a passive mechanical mount with no power draw.
