Meraki MA-PWR-ETH | USB-C Ethernet/PoE Adapter for MV2 and MT, 802.3af, 1m
SKU:MA-PWR-ETH
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The Meraki USB-C to Ethernet adapter is an optional accessory for powering a Meraki MV2 camera or MT environmental sensor from an 802.3af PoE switch port. It suits wired, PoE-powered deployments of MV2 indoor flex cameras, and gives MT sensors permanent power so batteries are no longer needed.
The adapter takes a single RJ-45 Ethernet input with IEEE 802.3af PoE and delivers up to 12.95 W over a USB-C output. A 1 m USB-C cable is part of this accessory. For the MV2 it provides both power and wired network connectivity. For MT10, MT11, MT14 and MT30 sensors it supplies PoE power only, with no data connection. Rectangular VHB tape strips are included for mounting the dongle.
It is the Ethernet/PoE alternative to the MA-PWR-USB-XX AC adapter, which provides 10 W at 5 V, 2 A. Either MA-PWR-USB-XX or MA-PWR-ETH is required to power an MV2. A PoE (802.3af) switch or injector is needed, and the connected camera or sensor carries its own Meraki licence.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Provides both power and wired network connectivity to the MV2 camera from a PoE switch
- Powers MT10, MT11, MT14 and MT30 sensors over PoE so batteries are no longer needed
- Accepts 802.3af PoE and delivers up to 12.95 W over USB-C
- Rectangular VHB tape strips for mounting the dongle
- Compatible alternative to the MA-PWR-USB-XX AC adapter
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Product ID: MA-PWR-ETH
- Network interface: 1 x Ethernet RJ-45 (PoE-in)
- Host interface: 1 x USB-C output
- PoE standard: IEEE 802.3af
- Maximum power: 12.95 W
- Cable: USB-C, 1 m (3.3 ft)
- Mounting: 2 x rectangular VHB tape strips
- Data connectivity: wired for MV2, power only for MT sensors
- Compatible with: MV2, MT10, MT11, MT14, MT30
- Wireless onboarding of MV2: not supported with this adapter
FAQs
Q: Does this adapter need a licence?
A: No licence is needed for the adapter itself. The connected MV camera or MT sensor requires its own Meraki licence.
Q: What power source does it need?
A: It needs an 802.3af PoE switch port or PoE injector. It delivers up to 12.95 W over USB-C to the connected device.
Q: Which Meraki devices does it work with?
A: It works with the MV2 camera and with MT10, MT11, MT14 and MT30 sensors. MT sensors receive power only, with no data connection.
Q: Can I claim it on my Meraki dashboard?
A: Yes. Every Meraki device XS Network Tech supplies can be claimed on your Meraki dashboard.
Q: How does it differ from the MA-PWR-USB-XX adapter?
A: MA-PWR-ETH is fed by Ethernet PoE and also provides wired connectivity to the MV2, while MA-PWR-USB-XX is an AC adapter providing 10 W at 5 V, 2 A. An MV2 needs one or the other.
