Meraki CW9177E | Wireless 9177 Wi-Fi 7 Outdoor Access Point, External

CW9177E

POA
POA
POA
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

The Cisco Wireless CW9177E is a tri-band Wi-Fi 7 outdoor access point engineered for demanding deployments requiring customised antenna coverage. With 4x4:4 MU-MIMO delivering up to 12 spatial streams across 2.4 GHz, 5 GHz, and 6 GHz bands, IP67-rated weatherproof enclosure, and integrated GPS/GNSS for AFC compliance, it supports stadiums, campuses, industrial sites, and smart city environments. Cloud or on-premises management provides deployment flexibility for high-density outdoor wireless.

Features

Tri-band Wi-Fi 7 (802.11be) with 4096-QAM and 320 MHz channel width on 6 GHz
- 12 spatial streams across three 4x4:4 radios (2.4 GHz, 5 GHz, 6 GHz)
- Multi-Link Operation (MLO) for aggregated multi-band connectivity and reduced latency
- Dedicated Cisco CleanAir Pro scanning radio for real-time spectrum intelligence across all three bands
- IP67-rated weatherproof enclosure for outdoor deployment in extreme environments
- Integrated GPS/GNSS receiver for AFC compliance and location-based services
- External antenna support with eight N-type connectors for customised RF design
- 10 Gbps multigigabit Ethernet and dual-rate SFP/SFP+ fiber uplink
- Bluetooth Low Energy (BLE) 6.0 radio for IoT, asset tracking, and wayfinding
- Cisco Ultra Reliable Wireless Backhaul (URWB) support for point-to-point connectivity
- OFDMA and uplink/downlink MU-MIMO for high-density user environments
- Preamble puncturing for efficient spectrum utilisation in interference-prone environments
- AI-enhanced Radio Resource Management (AI-RRM) for automated RF optimisation
- Flexible deployment: Cisco Meraki cloud or Catalyst 9800 on-premises management
- WPA3 security, 802.1X authentication, and AES encryption
- Operating temperature range: -40°C to +65°C with 100 mph wind tolerance

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

Wi-Fi Standard: 802.11be (Wi-Fi 7), backward compatible with 802.11a/b/g/n/ac/ax
- Radio Architecture: Tri-radio, tri-band with up to 12 spatial streams
- Frequency Bands: 2.4 GHz (4x4:4), 5 GHz (4x4:4), 6 GHz (4x4:4)
- Antenna Type: External antenna connectors (antennas sold separately), eight N-type female connectors
- Uplink: 10 Gbps multigigabit Ethernet (100M/1G/2.5G/5G/10G), dual-rate SFP/SFP+ fiber port (1/10 Gbps)
- Scanning Radio: Dedicated tri-band scanning radio with Cisco CleanAir Pro (2.4/5/6 GHz)
- IoT Radio: Integrated Bluetooth Low Energy (BLE) 6.0 radio for location and IoT applications
- Enclosure Rating: IP67-rated outdoor enclosure, weatherproof and dust-tight
- GPS/GNSS: Integrated GPS/GNSS receiver for AFC and location services
- Operating Temperature: -40°C to +65°C (-40°F to +149°F)
- Wind Tolerance: Sustained 100 mph winds
- Management: Cisco Meraki cloud or Catalyst 9800 on-premises controller
- Advanced Features: Multi-Link Operation (MLO), 4096-QAM, 320 MHz channel width (6 GHz), preamble puncturing, OFDMA, MU-MIMO
- Power: IEEE 802.3bt PoE++ (UPOE)

FAQs

Q: What antenna options are compatible with the CW9177E?
A: The CW9177E requires external antennas sold separately and supports a range of Cisco tri-band antennas including omnidirectional, directional, and sector antennas with N-type connectors. Compatible options include the CW-ANT-T-D4-N directional antenna (8/8/8 dBi) and CW-ANT-T-O3-N omnidirectional antenna (5/6/5 dBi), among others. The AP features eight N-type female connectors for customised coverage design.

Q: Can the CW9177E be managed on-premises or only in the cloud?
A: The CW9177E offers flexible management through either Cisco Meraki cloud or Cisco Catalyst 9800 on-premises wireless controllers. It is a global-use access point with unified hardware, allowing organisations to switch between management modes without replacing hardware. This provides deployment flexibility for hybrid or single-mode environments.

Q: What is the purpose of the integrated GPS/GNSS receiver?
A: The built-in GPS/GNSS receiver enables Automated Frequency Coordination (AFC) for 6 GHz standard power operation in outdoor deployments and provides intelligent regulatory-domain selection. It also supports precise location services for asset tracking and analytics applications, ensuring compliance with regional spectrum regulations.

Q: What outdoor environments is the CW9177E rated for?
A: The CW9177E features an IP67-rated enclosure providing complete protection against dust and water immersion. It operates in temperatures from -40°C to +65°C and is designed to withstand sustained winds of 100 mph. This makes it suitable for stadiums, campuses, industrial facilities, transportation hubs, ports, rail yards, and smart city deployments.

Q: Does the CW9177E require a Cisco Networking Subscription?
A: Yes, Cisco Wi-Fi 7 access points including the 9177 Series require a Cisco Networking Subscription with either Wireless Essentials or Wireless Advantage licenses. The subscription offers flexible on-premises, cloud, or hybrid management using unified licenses and hardware, with the ability to switch management modes as business needs evolve.
