Cisco WS-C2960+48TC-S | Catalyst 2960-Plus 48-Port Fast Ethernet Switch, LAN Lite
SKU:WS-C2960+48TC-S
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The Catalyst 2960-Plus 48TC-S is a fixed-configuration Fast Ethernet Layer 2 switch built for branch offices, remote sites and retail locations. It also suits conventional desktop workspaces and building infrastructure or physical security deployments that only need basic Layer 2 switching.
This model provides 48 10/100 Ethernet ports and 2 dual-purpose uplinks, each of which can run as SFP or 1000BASE-T. It is a non-PoE switch, so it has no PoE budget and powers itself from an internal auto-ranging AC supply rated 100 to 240 VAC, drawing roughly 30 W in typical use. Forwarding bandwidth is 16 Gbps with a forwarding rate of 10.1 Mpps, backed by 64 MB of flash and 128 MB of DRAM. It supports 64 active VLANs from a range of 4K VLAN IDs and occupies 1RU of rack space.
This SKU runs the LAN Lite Cisco IOS feature set, which is fixed to the model and cannot be upgraded to LAN Base. The uplinks accept SFP modules from the Cisco Transceiver Compatibility matrix, and an optional Cisco RPS 2300 (PWR-RPS2300) can be connected for redundant power.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Enterprise-class Layer 2 switching for branch offices, workspaces and infrastructure
- Cisco Catalyst SmartOperations including Smart Install, Auto Smartports and Smart Troubleshooting
- Cisco EnergyWise technology to measure and manage the energy use of connected devices
- QoS with four egress queues per port, strict priority queuing, SRR scheduling and up to 64 policers per port
- Security features including Flexible Authentication, 802.1X Monitor Mode, Port Security, Dynamic ARP Inspection and IP Source Guard
- Standards support including 802.1Q, 802.1X, LLDP, 802.3ad, SNMP v1/v2c/v3, RMON and IPv6
- Optional Cisco RPS 2300 redundant power system support
- Managed through Cisco Prime Infrastructure
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- 10/100 Ethernet ports: 48
- Uplink ports: 2 dual-purpose (SFP or 1000BASE-T)
- Cisco IOS feature set: LAN Lite
- PoE: None (non-PoE model)
- Forwarding bandwidth: 16 Gbps
- Forwarding rate (64-byte L3 packets): 10.1 Mpps
- Maximum active VLANs: 64
- VLAN IDs available: 4K
- MTU (L3 packet): 9000 bytes
- Jumbo frame (Ethernet frame): 9018 bytes
- Flash memory: 64 MB
- DRAM: 128 MB
- Dimensions (H x W x D): 1.73 x 17.70 x 9.52 in (4.4 x 45.0 x 24.2 cm)
- Weight: 3.6 kg (8 lb)
- Form factor: 1RU rack-mount
- AC input: 100 to 240 VAC autoranging, 50 to 60 Hz
- Power consumption: 29.9 W at 0% traffic, 30.2 W at 100% traffic
- DC input (RPS): 3 A at 12 V
- Operating temperature up to 1500 m: -5 to 45 C
- Operating temperature up to 3000 m: -5 to 40 C
- Storage temperature: -25 to 70 C
- Relative humidity: 10% to 95% noncondensing
- Acoustic noise (sound pressure, typical/max): 33 / 36 dBA
- MTBF: 623,000 hours
FAQs
Q: Does this switch provide Power over Ethernet?
A: No. This is a non-PoE model with no PoE budget. It suits connected devices that are powered separately.
Q: Can the LAN Lite software be upgraded to LAN Base?
A: No. The LAN Lite feature set is fixed to this model and cannot be upgraded to LAN Base. Software updates are free to registered customers.
Q: What can be fitted to the two uplink ports?
A: The two dual-purpose uplinks work as either 1000BASE-T copper or SFP. SFP modules are supported per the Cisco Transceiver Compatibility matrix.
Q: Can it be connected to a redundant power supply?
A: Yes. The Cisco RPS 2300 (PWR-RPS2300) can be connected through the RPS connector, which uses a DC input of 3 A at 12 V.
Q: How many VLANs does the LAN Lite feature set support?
A: LAN Lite supports up to 64 active VLANs, selected from a range of 4K VLAN IDs.
