• Cisco VG450-144FXS/K9 black chassis with FXS ports, vents, and power supply
1 1

Cisco

Cisco VG450-144FXS/K9 | VG450 144-Port FXS Analog Voice Gateway, 2x SM-X-72FXS

VG450-144FXS/K9

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Cisco VG450 is a rack-mount analog voice gateway running Cisco IOS-XE, built to connect analog phones, fax machines, modems and speakerphones to Cisco Unified Communications Manager or UCM Express. It suits centralised, high-concentration analog line deployments where existing analog endpoints need to stay in service while the network moves to IP telephony, and it can augment an ISR environment running Cisco Unified Communications Manager Express.

This 144 FXS bundle uses two SM-X-72FXS double-wide modules (RJ-21) to deliver 144 FXS ports in a single 3RU chassis, set apart from the 72 FXS and chassis-only VG450 variants. Each module supports FXS-E extended loop operation, and the gateway handles loop-start, ground-start and DID signalling. Four 10/100/1000 Ethernet LAN ports can each use SFP-based fibre in place of RJ-45. The chassis ships with 8GB DDR4 DRAM and 8GB flash, expandable to 32GB of each, and has a 100-240 VAC auto-ranging supply rated to 1000W with no PoE.

Call control is supported on Cisco UCM 10.5.2 (SU8), 11.5.1SU6 or higher, or 12.0.1SU2 or higher, with UCM Express on CUCME versions compatible with IOS-XE 16.12.1 or later. Third-party call control is supported through SIP and H.323 IP trunks. The mix-and-match NIM slot accepts analog (FXO, FXS, E&M, BRI) and T1/E1 voice NIMs.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Cisco IOS-XE software-based gateway with uniform Cisco CLI and SNMPv3 support
- Supports analog phones, fax machines, modems and speakerphones as extensions of Cisco UCM or UCM Express
- T.38 fax relay, fax pass-through and modem pass-through
- MGCP fallback for call availability
- Protocols include SCCP, H.323v4, MGCP, SIP, RTP and SRTP, with G.711 and G.729a codecs
- RADIUS and TACACS+ support for access control
- Optional integrated Redundant Power System for power redundancy
- Mix-and-match NIM slot for analog (FXO, FXS, E&M, BRI) and T1/E1 voice NIMs

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- FXS ports: 144 (2 x SM-X-72FXS modules, RJ-21)
- Ethernet: 4 x 10/100/1000 LAN ports, SFP-capable in lieu of RJ-45
- DRAM: 8GB DDR4 default, 32GB maximum
- Flash: 8GB default, 32GB maximum
- USB: 2 x USB 2.0 Type-A
- Console: mini-B USB console plus traditional console and auxiliary ports
- FXS signalling: loop-start, ground-start and DID
- FXS-E ports per module: Mode 1: 16 FXS-E / 56 FXS; Mode 2: 56 FXS-E / 16 disabled
- Short-loop reach: 3000 ft (900 m) at 26 AWG, 5500 ft (1700 m) at 24 AWG
- Long-loop reach: 11,000 ft (3400 m) at 26 AWG, 18,000 ft (5500 m) at 24 AWG
- Ring voltage: 54 Vrms into 5 RENs (short-loop), 65 Vrms into 2 RENs (long-loop)
- Ring frequency: 20, 25, 30 and 50 Hz
- Echo cancellation: up to 128 ms echo tail
- Power input: 100 to 240 VAC auto-ranging, 47 to 63 Hz, 7.1 to 3.0 A
- Maximum power: 1000W with AC supply (no PoE), 230W maximum power dissipation
- Mounting: 3RU, 19 in. EIA / 23 in. rack-mount
- Dimensions (W x H x D): 438.15 x 132.6 x 477.65 mm
- Weight: 18.3 kg maximum
- Operating temperature: 0 to 40 C
- Operating humidity: 5 to 85%
- Noise level: sound pressure 54.3 dB typical, 68.9 dB maximum

FAQs

Q: Does the VG450 144 FXS need a separate licence?
A: No separate licence is stated in the datasheet. The gateway runs Cisco IOS-XE. CUBE, CUCME/SRST and DSP-farm functions are not natively supported and are only available on ISR4000.

Q: What call control platforms does it work with?
A: It works with Cisco UCM 10.5.2 (SU8), 11.5.1SU6 or higher, or 12.0.1SU2 or higher. UCM Express is supported on CUCME versions compatible with IOS-XE 16.12.1 or later. Third-party call control is supported via SIP and H.323 IP trunk.

Q: What power does the VG450 144 FXS need?
A: It takes 100-240 VAC auto-ranging at 47-63 Hz, with a maximum of 1000W and 230W maximum power dissipation. It provides no PoE. An optional integrated Redundant Power System is available.

Q: How does this SKU differ from the VG450-72FXS/K9 and the chassis-only VG450/K9?
A: This SKU is the 144 FXS bundle with two SM-X-72FXS modules fitted. The VG450-72FXS/K9 provides 72 FXS ports, and the chassis-only VG450/K9 has no FXS modules.

Q: Which voice NIMs can be used in the NIM slot?
A: Supported NIMs are NIM-2FXO, NIM-4FXO, NIM-2FXSP, NIM-4FXSP, NIM-2FXS/4FXOP, NIM-4E/M, NIM-2BRI-NT/TE, NIM-4BRI-NT/TE and NIM-1/2/4/8MFT-T1/E1. SM-X-NIM-ADPTR is not supported.
