• Black metal 2.5-inch solid-state drive with matte finish and four corner screws cisco UCSX-NVE16T4S1P 6.4TB NVMe SSD
1 1

Cisco

Cisco UCSX-NVE16T4S1P | UCS X-Series 6.4TB E3.S NVMe SSD, Gen5, 3X DWPD, OPAL

UCSX-NVE16T4S1P

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This 6.4TB NVMe solid state drive is built for Cisco UCS X-Series M8 compute nodes. It uses the compact EDSFF E3.S 1T form factor with a PCIe Gen5 x4 interface and is based on the PM1745 high performance, high endurance design, making it a strong fit for write-heavy local storage in databases, virtualisation, AI and analytics workloads, and vSAN all-NVMe capacity tiers.

The drive is rated in the 3X DWPD endurance class and supports TCG Opal self-encryption for hardware-based data-at-rest security. It is hot-swappable from the front mezzanine of the compute node and draws power from the host node, so no separate power supply is needed. A UCS X210c M8 node can hold up to 9 E3.S drives.

This drive works with the Cisco UCS X210c M8 and X215c M8 compute nodes and requires the UCSX-X10C-PTE3 E3.S pass-through front mezzanine controller. E3.S drives cannot be mixed with 2.5in SAS, SATA or U.3 drives in the same node. It is also listed for the Cisco Compute Hyperconverged HCIXVS210C M8 and HCIVS240C M8 E3.S vSAN ReadyNodes.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Gen5 NVMe performance in the compact EDSFF E3.S 1T form factor
- High-endurance 3X DWPD class design for write-intensive workloads
- TCG Opal support for hardware-based data-at-rest security
- Hot-swappable from the compute node front mezzanine
- Suited to databases, virtualisation, AI and analytics workloads
- Supported on Cisco UCS X210c M8 and X215c M8 compute nodes
- Listed for HCIXVS210C M8 and HCIVS240C M8 E3.S vSAN ReadyNodes

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Capacity: 6.4TB
- Drive type: NVMe SSD
- Form factor: EDSFF E3.S 1T
- Interface: PCIe Gen5 x4 NVMe
- Performance class: High Performance (PM1745)
- Endurance class: High Endurance, 3X DWPD
- Security: TCG Opal self-encrypting support
- Hot-swappable: Yes, from the compute node front mezzanine
- Required front mezzanine: UCSX-X10C-PTE3 (UCS X10c Compute Pass Through Controller for E3.S)
- Maximum drives per UCS X210c M8 node: 9 E3.S drives
- Mixing: Cannot be mixed with 2.5in SATA, SAS or U.3 drives
- Power: Supplied by the host compute node, no separate power supply

FAQs

Q: Which UCS compute nodes does this drive work with?
A: It is supported on the Cisco UCS X210c M8 and X215c M8 compute nodes. It is also listed for the Cisco Compute Hyperconverged HCIXVS210C M8 and HCIVS240C M8 E3.S vSAN ReadyNodes.

Q: What front mezzanine controller is required?
A: The UCSX-X10C-PTE3 UCS X10c Compute Pass Through Controller for E3.S is required. It provides the E3.S drive bays in the compute node.

Q: How many of these drives can one compute node hold?
A: A UCS X210c M8 node supports up to 9 E3.S drives. E3.S drives cannot be mixed with 2.5in SATA, SAS or U.3 drives in the same node.

Q: Does the drive need a separate power supply?
A: No. It is powered from the host compute node through the E3.S front mezzanine. The Cisco UCS Power Calculator can provide configuration-specific power figures.

Q: Does this drive support hardware encryption?
A: Yes. It supports TCG Opal self-encryption for hardware-based data-at-rest security.
