Cisco

Cisco SG550XG-8F8T | 550X 16-Port 10G Switch, 8x 10GBase-T, 8x SFP+

SKU:SG550XG-8F8T

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The SG550XG-8F8T is a 16-port 10 Gigabit stackable managed switch from the Cisco 550X Series. It suits small and medium businesses that need a high-performance backbone or aggregation layer, connecting servers and network storage over 10G copper or fibre, or aggregating SG550X access switches over 10G SFP+ uplinks.

The port layout is 8x 10GBase-T copper ports and 8x dedicated 10G SFP+ slots, plus a Gigabit out-of-band management port. Switching capacity is 320 Gbps, wire-speed and non-blocking, with a forwarding rate of 238.08 Mpps. Up to 8 units can be hardware stacked and managed as a single system. It is a non-PoE model with an internal universal 100-240V AC supply, and no separate software licence or subscription is required.

It works with Cisco SFP and SFP+ modules including SFP-10G-SR, SFP-10G-LR and SFP-H10GB-CU direct attach cables, and stacks with other 550X Series models such as the SF550X, SG550X and SX550X. An external Cisco RPS2300 can be connected through the RPS connector for redundant power.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- True hardware stacking of up to 8 units in ring or chain topologies, with a unified data, control and management plane
- Hybrid stacking with SF550X, SG550X, SG550XG and SX550X models
- Layer 3 features including wire-speed IPv4 routing, IPv6 static routing, RIP v2, VRRP, policy-based routing and DHCP server
- Security features including 802.1X, DHCP snooping, IP Source Guard, Dynamic ARP Inspection, storm control and ACLs
- QoS with 8 hardware queues, DiffServ, rate limiting and iSCSI traffic optimisation
- Dual software images for upgrades without downtime
- Energy Efficient Ethernet (802.3az), energy detect and cable length detection
- Management via web UI, Smart Network Application, SNMP v1/v2c/v3, CLI, LLDP-MED and Cisco Discovery Protocol

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Ports: 8x 10GBase-T copper plus 8x 10 GE SFP+
- Management port: 1x Gigabit Ethernet out-of-band
- Console port: RJ-45
- USB: Type-A on front panel
- Switching capacity: 320 Gbps, wire-speed non-blocking
- Forwarding rate: 238.08 Mpps (64-byte packets)
- Stacking: up to 8 units, up to 400 ports
- MAC table: 32,000 addresses
- Packet buffer: 2 MB
- CPU: 800 MHz dual-core ARM
- CPU memory: 512 MB
- Flash: 256 MB
- Jumbo frames: up to 9000 bytes
- ACLs: up to 2000 entries
- IPv4 routing: up to 7,168 routes and 256 IP interfaces
- IPv6 static routing: up to 1,792 routes and 256 IPv6 interfaces
- Power supply: internal universal, 100-240V, 47-63 Hz
- Power consumption (worst case, green mode): 84.3 W at 110V, 84.6 W at 220V
- Heat dissipation: 288.67 BTU/hr
- Dimensions (W x H x D): 440 x 44 x 350 mm, 1U rack-mount
- Weight: 5.23 kg
- Fans: 3 + 1 redundant
- Operating temperature: 0 to 50 C
- Operating humidity: 10% to 90% non-condensing
- Certifications: UL 60950, CSA 22.2, CE mark, FCC Part 15 Class A

FAQs

Q: Does the SG550XG-8F8T need a software licence?
A: No. The full feature set is standard, so no separate software licence or subscription is required.

Q: Does this switch support PoE?
A: No. It is a non-PoE model. It runs from an internal universal 100-240V AC supply.

Q: Which optics and cables work with the SFP+ ports?
A: Cisco-listed modules include SFP-10G-SR, SFP-10G-LR, SFP-10G-SR-S, SFP-10G-LR-S and SFP-H10GB-CU1M, 3M and 5M direct attach cables. For 1G operation, 1G SFP modules are needed at both ends of the link.

Q: Can it be stacked with other switches?
A: Yes. Up to 8 units can be stacked, and it can be mixed with SF550X, SG550X, SG550XG and SX550X models in the same stack.

Q: Can it have redundant power?
A: Yes. An external Cisco RPS2300 redundant power system can be connected through the RPS connector. The switch also has N+1 redundant fans.
