• Cisco PWR-RGD-AC-DC rugged PSU in black server chassis with green accents
1 1

Cisco

Cisco PWR-RGD-AC-DC | Rugged Power Supply, 150W, 88-300VDC / 85-264VAC

PWR-RGD-AC-DC

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The PWR-RGD-AC-DC is a rugged, hot-plug power supply module for Cisco Connected Grid and industrial Ethernet platforms. It suits power substations, transmission and distribution automation, and utility or industrial field networks that need a high-voltage AC or DC feed, with the option of redundant power on compatible platforms.

The module accepts 85 to 264 VAC at 47 to 63 Hz, or 88 to 300 VDC, one input type at a time, and provides 150 W of output capacity. It is the high-voltage variant, distinct from the PWR-RGD-LOW-DC module that covers 24/48 V DC input. Operating temperature runs from -40 to 60 C with 5 to 95 percent non-condensing humidity, and the module measures 1.6 x 7 x 5 inches.

It is used with the Cisco CGR 2010 Connected Grid Router and the CGS 2520 Connected Grid Switch (CGS-2520-16S-8PC and CGS-2520-24TC), and in IE 3010 series switches. When installed in the CGS 2520 it can also power PoE ports.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Wide-range high-voltage AC or DC input, one input type at a time, for flexible deployment
- Hot-plug module supporting redundant dual-supply operation on compatible platforms
- Rugged design for power substation and industrial environments
- Suited to convection-cooled, fanless host platforms
- Can power PoE ports on the CGS 2520 when installed

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Device type: Power supply, hot-plug / redundant plug-in module
- AC input range: 85-264 VAC, 47-63 Hz
- DC input range: 88-300 VDC
- Nominal input: 100-240 VAC 50-60 Hz / 100-250 VDC
- Output capacity: 150 W
- Operating temperature: -40 to 60 C
- Operating humidity: 5-95% non-condensing
- Dimensions (H x W x D): 1.6 x 7 x 5 in
- Weight: approx. 2.54 lb
- CGS-2520-16S-8PC with one module, no PoE: AC 43.2 W / DC 40.3 W
- CGS-2520-16S-8PC with one module, PoE on 4 ports: AC 110.1 W / DC 109.8 W
- CGS-2520-24TC with one module: AC 29.8 W / DC 28.6 W

FAQs

Q: Does it accept both AC and DC input?
A: Yes, it accepts 85-264 VAC at 47-63 Hz or 88-300 VDC. Only one input type is used at a time.

Q: Which Cisco platforms is it used with?
A: It is used with the CGR 2010 Connected Grid Router and the CGS 2520 Connected Grid Switch, and in IE 3010 series switches.

Q: How does it differ from PWR-RGD-LOW-DC?
A: PWR-RGD-AC-DC is the high-voltage module for 85-264 VAC or 88-300 VDC input. PWR-RGD-LOW-DC is the low-voltage companion module for 24/48 V DC input.

Q: Can two modules be installed for redundancy?
A: Yes, on compatible platforms such as the CGS 2520 it works as a hot-plug redundant module, so a second supply can be fitted for dual-supply operation.

Q: Can it power PoE ports?
A: On the CGS 2520 it can power PoE ports. For example, the CGS-2520-16S-8PC with one module and PoE on 4 ports draws about 110 W.
