Cisco PWR-IE170W-PC-A | IE 4000 170W DIN-Rail Power Supply, AC/DC Input

SKU:PWR-IE170W-PC-A

Stock Status: Enquire

Request Quote

Sale Sold out

Shipping calculated at checkout.

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This 170W DIN-rail power supply powers Cisco Industrial Ethernet switches, including the IE 4000 and IE 1000 ranges, and supports PoE and PoE+ ports. It accepts wide-range AC 90-264V or high-voltage DC 106-300V input and delivers 54VDC output. The fanless, rugged design operates from -40°C to +75°C with no derating and is approved for Class 1 Div 2 and Zone 2 hazardous locations. This AC/high-voltage DC variant suits industrial installations where mains or high-voltage DC supply is available.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- DIN-rail mountable
- Powers IE 4000 and IE 1000 series switches
- Supports up to 8 PoE ports or 5 PoE+ ports on IE 1000 when used in an AC environment
- Wide-range AC or high-voltage DC input
- Fanless, rugged design for harsh industrial environments
- Certifications include CE, UL/CSA 60950-1, CB Scheme, CCC and BSMI
- IEC 61850-3 and IEEE 1613 compliance listed

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Max output power: 170W
- Input: AC 90-264V (nominal 100-240V, 2.3A, 50-60Hz) or DC 106-300V (nominal 125-250V, 2.1A)
- Output: 54VDC, 3.15A
- Typical efficiency: 88%
- Inrush current: less than 35A at 115VAC and 70A at 230VAC
- Holdup time at 100% load: 20ms
- PoE/PoE+ support: Yes
- Protections: over voltage, over current, over temperature, short circuit
- IP20 rating
- Operating temperature: -40°C to +75°C with no derating
- Storage temperature: -40°C to +85°C
- Humidity: less than 95% RH non-condensing
- Dimensions (W x H x D): 96 x 150 x 146 mm
- Weight: 1.76 kg
- MTBF: 2,384,975 hours
- Approved for Class 1, Div 2 / Zone 2 hazardous locations, CSA certified

FAQs

Q: Which switches does this power supply support?
A: It powers Cisco Industrial Ethernet IE 4000 series and IE 1000 series switches, including their PoE and PoE+ ports.

Q: What input voltages does it accept?
A: It accepts AC 90-264V (nominal 100-240V, 50-60Hz) or DC 106-300V (nominal 125-250V), making it suited to mains or high-voltage DC supplies.

Q: What is the output voltage and power?
A: It delivers 54VDC at up to 3.15A, for a maximum output power of 170W.

Q: How does this differ from the PWR-IE170W-PC-DC= variant?
A: This model takes AC 90-264V or DC 106-300V input, while the DC variant is designed for low-voltage DC input of 10.8-60V.

Q: Can it operate in extreme temperatures?
A: Yes. It operates from -40°C to +75°C with no derating, and is fanless with over voltage, over current, over temperature and short circuit protection.
