Cisco N540X-ACC-SYS | NCS 540 24x 10G SFP+ Router, 2x 100G, Conformal Coated
SKU:N540X-ACC-SYS
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The Network Convergence System 540 is a fixed 1RU, temperature-hardened IOS XR access and aggregation router built for service-provider mobile backhaul and fronthaul, business and residential services, and timing-sensitive 4G/5G transport. This conformal-coated variant is intended for hot and humid conditions, including indoor and outdoor cabinet deployments.
The chassis provides 24x 1GE/10GE SFP/SFP+ ports, 8x 1GE/10GE/25GE SFP28 ports and 2x 40GE/100GE QSFP28 ports, with forwarding performance of up to 300 Mpps. It is powered by a 4-core 1.5 GHz x86 CPU with 16GB DRAM and 128GB storage. Two hot-swappable AC/DC power supplies run in 1+1 redundancy, and four modular fans provide 3+1 cooling with front-to-back airflow. The industrial temperature range is -40°C to +70°C, and SyncE, PTP and an integrated GNSS receiver (Class B) cover precise frequency and time synchronisation.
The router runs Cisco IOS XR, licensed through Access Essentials or Access Advantage right-to-use or subscription licences ordered per 10G. It works with the N540-PWR400-A and N540-PWR400-D power supplies, the N540-X-FAN fan module and the N540-RCKMT-19, N540-RCKMT-23 and N540-RKMT-ETSI rackmount options.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Cisco IOS XR with Segment Routing (SR-MPLS, SRv6), MPLS, EVPN/VPLS, L3VPN and TI-LFA
- Conformal coating for hot, humid conditions and outdoor cabinet deployments
- Precise frequency and phase/time synchronisation with SyncE, IEEE 1588 PTP and an integrated GNSS receiver
- Hierarchical QoS with VOQ and deep packet buffers
- Trust anchor hardware with secure boot, image signing and run-time defence
- Model-driven programmability and telemetry with NETCONF/gRPC, YANG, OpenConfig and ZTP
- Low-latency forwarding, typically under 10 µs
- MEF 3.0 compliant
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Chassis: Fixed 1RU, conformal coated
- Ports: 24x 1GE/10GE SFP/SFP+
- Ports: 8x 1GE/10GE/25GE SFP28
- Ports: 2x 40GE/100GE QSFP28
- Forwarding performance: Up to 300 Mpps
- CPU: 4-core 1.5 GHz x86
- Memory: 16GB DRAM
- Storage: 128GB
- Power supplies: 2x hot-swappable AC/DC, 1+1 redundancy
- Fans: 4 modular fans, 3+1 redundant cooling
- Airflow: Front-to-back
- Operating temperature: -40°C to +70°C at 1,000 ft
- Operating humidity: 5% to 95% (non-condensing)
- Altitude: 0 to 13,000 ft
- AC input power: 90-265V, 50-60 Hz
- DC input power: -40V to -72V
- Timing: SyncE, PTP, integrated GNSS receiver, Class B
- Timing interfaces: 1pps, 10MHz, ToD, GNSS antenna
- Dimensions: 1RU, 1.72 x 17.3 x 10.1 in (depth 26 cm)
- Weight: 5.9 kg
- Typical latency: Under 10 µs
- Power consumption: Typical under 200W, maximum 250W
- Compliance: NEBS GR-63-CORE and GR-1089-CORE
FAQs
Q: Does the N540X-ACC-SYS need a software licence?
A: It runs Cisco IOS XR, which is licensed through Access Essentials or Access Advantage right-to-use or subscription licences ordered per 10G.
Q: What power supplies does it use?
A: It takes two hot-swappable power supplies in 1+1 redundancy. Use the N540-PWR400-A for AC input (90-265V) or the N540-PWR400-D for DC input (-40V to -72V).
Q: How does it differ from the N540-ACC-SYS?
A: The N540X-ACC-SYS is the conformal-coated version of the same chassis, intended for hot and humid conditions. The port layout and 16GB DRAM are the same.
Q: What rackmount options are available?
A: The N540-RCKMT-19, N540-RCKMT-23 and N540-RKMT-ETSI rackmounts are supported, along with the N540-CBL-GD-19 cable guide bracket.
Q: Can it provide timing for 4G and 5G transport?
A: Yes. It supports SyncE and IEEE 1588 PTP with an integrated GNSS receiver and 1pps, 10MHz and ToD interfaces, meeting Class B timing requirements.
