Cisco N520-X-20G4Z-A | NCS 520 Router, 4x 10G SFP+, Industrial Temp, AC
SKU:N520-X-20G4Z-A
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The Cisco NCS 520 is a fixed 1RU carrier Ethernet demarcation router built for service providers. It is Layer 2 and Layer 3 capable and MEF 3.0 certified, making it suited to network interface device roles between the customer LAN and the provider network, including mobile backhaul, business Ethernet and cloud access services. This industrial temperature, AC-powered model is rated for uncontrolled and outdoor cabinet locations and NEBS Level 3 environments.
This 24-port model provides 4 x 1G copper ports, 16 x 1G SFP ports and 4 x 1/10G SFP+ ports. It has dual AC power supplies accepting 85 to 264 V AC, with a maximum input power of 110 W, and five integrated fans in a 4+1 redundant arrangement. The operating range is -40 to 70 C at lower altitudes, and the chassis uses front-to-back airflow in a 1 RU, 19 inch width footprint. It runs Cisco IOS XE, and pay-as-you-grow port upgrade licensing is available alongside Smart Licensing.
Optics support includes 100M, 1G and 10G SFP and SFP+ modules, such as GLC-SX-MMD, GLC-LH-SMD, SFP-10G-SR, SFP-10G-LR and SFP-H10GB-CU direct attach cables, plus extended temperature SFP-10G-SR-X and SFP-10G-LR-X. ETSI, 19 inch and 23 inch rack mount kits are available for the chassis.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- MEF 3.0 certified carrier Ethernet demarcation for ELINE, ELAN, ETREE, Access ELINE and Transit ELINE services
- Zero-Touch Provisioning (ZTP) via a front-panel button
- Class-based 3-level hierarchical QoS with ingress policing, egress shaping and deep packet buffers
- OAM and service assurance including Y.1731 PM, 802.1ag CFM, Y.1564 service turn-up and TWAMP responder
- Layer 2 features including bridge domains, 802.1Q and Q-in-Q, LACP, G.8032 and PVST/RPVST+
- Layer 3 features including IPv4 routing, VRF-Lite, OSPF, IS-IS, BGP and VRRP/HSRP
- Secure boot with signed image and Trust Anchor module, plus DHCP snooping, dynamic ARP inspection and AAA/TACACS+
- Managed through CLI, SNMP, NETCONF and YANG models
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Product ID: N520-X-20G4Z-A
- 1G copper ports: 4
- 1G SFP ports: 16
- 1/10G SFP+ ports: 4
- Power supplies: 2 x AC (no DC PSU)
- AC input voltage: 85 to 264 V AC (nominal 100 to 240 V AC)
- AC input frequency: 47 to 63 Hz
- Maximum input power: 110 W (375 BTU/hr)
- Fan redundancy: 4+1 (5 integrated fans)
- Airflow: Front-to-back
- Operating temperature: -40 to 70 C up to 300 m; -40 to 65 C up to 1,800 m; -40 to 55 C up to 4,000 m
- Relative humidity: 5 to 95 percent, non-condensing
- Height: 1.75 in. (1 RU)
- Width: 17.5 in.
- Depth: 9 in.
- Weight: 8.38 lb (3.8 kg)
- Rack mounts: ETSI, 19 in. and 23 in. kits
- Chassis MTBF at 40 C: 348,000 hours
- Seismic: Zone 4
- NEBS: GR-63-CORE, GR-1089-CORE, SR-3580 Level 3, GR-3108
- Software: Cisco IOS XE
FAQs
Q: Which licences does the NCS 520 use?
A: It runs Cisco IOS XE. The base software licence is N520-S-M (Metro Access License), with port upgrade licences N520-1G-8 and N520-10G-2 available as you grow. Smart Licensing is supported alongside PAK licensing.
Q: What power does this model use?
A: It has dual AC power supplies accepting 85 to 264 V AC at 47 to 63 Hz. Maximum input power is 110 W. There is no DC power supply option on this SKU.
Q: Which optics work with the 10G SFP+ ports?
A: Supported 10G modules include SFP-10G-SR, SFP-10G-LR, SFP-10G-ER, SFP-10G-ZR, SFP-10G-LRM and SFP-H10GB-CU1M, 3M and 5M direct attach cables. Extended temperature SFP-10G-SR-X and SFP-10G-LR-X suit the full industrial range.
Q: What rack mounting options are available?
A: The 24-port chassis supports N520-RCKMT-19-D3A for 19 inch racks, N520-RCKMT-23-D3A for 23 inch racks and N520-RMT-ETSI-D3A for ETSI racks. A wall mount kit, N520-WALLMT, is also available.
Q: How does this SKU differ from other NCS 520 models?
A: This is the 24-port industrial temperature model with AC power. It provides 4x 1G copper, 16x 1G SFP and 4x 1/10G SFP+ ports and has no DC power supply.
