Cisco

Cisco CW9174I-RTG | Wireless 9174 Wi-Fi 7 Tri-Band Indoor Access Point

CW9174I-RTG

POA
POA
POA
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

The Cisco CW9174I-RTG is a high-performance Wi-Fi 7 indoor access point designed for moderate to high-density enterprise environments. Featuring tri-band operation across 2.4 GHz, 5 GHz, and 6 GHz frequencies with 4x4:4 MU-MIMO, integrated omnidirectional antennas, and a dedicated scanning radio, it delivers superior connectivity and advanced IoT support. This global-use access point works seamlessly with both Cisco Catalyst 9800 Series Wireless Controllers and Cisco cloud management, offering flexible deployment options for modern enterprises.

Features

Wi-Fi 7 (802.11be) with 4K-QAM modulation for maximum throughput
- Multi-Link Operation (MLO) for simultaneous transmission across multiple bands
- Preamble puncturing to maintain performance despite channel interference
- 320 MHz channel width support in 6 GHz band
- 4x4:4 MU-MIMO for concurrent client connections
- OFDMA for efficient spectrum utilization in high-density environments
- Dedicated scanning radio for real-time RF monitoring and optimization
- Integrated Bluetooth 5.3 LE for IoT applications, asset tracking, and wayfinding
- Target Wake Time (TWT) for improved battery life on client devices
- AI-Enhanced Radio Resource Management (AI-RRM) for automated optimization
- Cisco CleanAir Pro technology for spectrum intelligence
- WPA3 security with enhanced encryption
- Dynamic Frequency Selection (DFS) for optimal channel utilization
- USB 2.0 port for GPS module and external accessories
- Automatic management mode discovery (WLC or Meraki)
- Band steering to optimize client distribution across frequencies

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

Wi-Fi Standard: IEEE 802.11be (Wi-Fi 7), backward compatible with 802.11a/b/g/n/ac/ax
- Radio Configuration: Five radios - tri-band mode with 2.4 GHz (2x2:2 or 4x4:4), 5 GHz (4x4:4), 6 GHz (4x4:4), dedicated scanning radio, and IoT radio
- Spatial Streams: Up to 10 spatial streams in tri-band mode, 8 streams in dual-band mode
- Integrated Antennas: Internal omnidirectional antennas for all bands
- Maximum Aggregate Throughput: Up to 17.5 Gbps
- Ethernet Port: 1x multigigabit Ethernet (RJ-45) supporting 100 Mbps, 1 Gbps, 2.5 Gbps, and 5 Gbps
- Power over Ethernet: 802.3at (PoE+) or 802.3bt (UPOE) - typical power consumption 18.2W (PoE+) / 20.6W (UPOE)
- USB Port: USB 2.0 with 2.5W output (PoE+) or 9W output (UPOE) for accessories
- Bluetooth: Bluetooth 5.3 Low Energy for IoT applications and location services
- Management: Cisco Catalyst Center, Cisco Catalyst 9800 Series Controllers, or Meraki cloud dashboard
- Operating Temperature: 0°C to 50°C (32°F to 122°F)
- Dimensions: Standard indoor AP form factor
- Mounting: Suspended ceiling, wall mount (brackets sold separately)

FAQs

Q: What makes the CW9174I-RTG a global-use access point?
A: The CW9174I-RTG features a single SKU that works globally, automatically detecting regulatory domains and management modes. It eliminates the need for region-specific product variants, simplifying procurement and deployment across international locations.

Q: Can this access point work with both Meraki cloud and on-premises controllers?
A: Yes, the CW9174I-RTG is a unified access point that seamlessly operates with both Cisco Catalyst 9800 Series Wireless Controllers for on-premises management and the Meraki cloud dashboard. It automatically detects the appropriate management mode during deployment.

Q: What is the difference between tri-band and dual-band operation modes?
A: In tri-band mode, the CW9174I operates across 2.4 GHz (2x2:2), 5 GHz (4x4:4), and 6 GHz (4x4:4) for 10 spatial streams. In dual-band mode, it operates at 2.4 GHz (4x4:4) and 5 GHz (4x4:4) for 8 spatial streams, useful in regions where 6 GHz spectrum is not yet available.

Q: What PoE power option is recommended for full functionality?
A: For full functionality including 5 Gbps uplink speeds, all radio streams, and 9W USB power, 802.3bt UPOE is recommended. The access point also supports 802.3at PoE+ with reduced uplink speed (2.5 Gbps), lower USB power (2.5W), and limited radio functionality.

Q: What deployment scenarios is the CW9174I best suited for?
A: The CW9174I is ideal for moderate to high-density indoor environments including corporate offices, healthcare facilities, retail stores, educational institutions, and hospitality venues. Its omnidirectional antennas provide even coverage in open areas and multi-room layouts.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.
