Cisco C819HGW-7-N-K9 | 819 Hardened 3G HSPA+ R7 Router, Dual Wi-Fi, ANZ
SKU:C819HGW-7-N-K9
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The Cisco 819 hardened integrated services router is a compact Cisco IOS platform built for machine-to-machine (M2M) deployments. It combines an embedded 3G HSPA+ Release 7 modem with a dual-radio 802.11a/b/g/n access point and an ANZ regulatory domain, making it suited to industrial automation, transportation and vehicles, utilities, healthcare, retail and small branch sites needing primary or backup 3G WAN.
The embedded Sierra Wireless MC8705 modem supports HSPA+ on 850, 900, 1900 and 2100 MHz with up to 21 Mbps downlink and 5.76 Mbps uplink, plus two internal SIM slots for multihoming and failover. SMS and standalone GPS are supported. Wired connectivity is one Gigabit Ethernet WAN port, four Fast Ethernet LAN ports and a Cisco Smart Serial interface. The 2x3 MIMO Wi-Fi radios deliver PHY rates up to 300 Mbps. It carries 1 GB DRAM and 1 GB flash and runs Cisco IOS Software 15.2(4)M1 or later. Operating range is -25 to 60 C, with a 20 W maximum platform draw.
It works with the PWR2-20W-AC, PWR2-20W-12VDC and PWR2-20W-24VDC power adapters and the CAB-SS Smart Serial cable range.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Compact Cisco IOS router with integrated 3G WWAN and WLAN for M2M applications
- Concurrent 3G WAN backhaul and dual-radio Wi-Fi on one platform
- Dual SIM support for cellular multihoming and failover
- Auto-switch failover between primary and backup links
- Remote 3G firmware upgrade and SMS callback
- Hardware-accelerated IPsec, SSL VPN, Easy VPN, DMVPN and GET VPN
- Zone-Based Firewall, IPS and content filtering support
- Routing with RIP, OSPF, EIGRP, BGP and PfR, with IPv4, IPv6 and QoS
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Cellular modem: Embedded Sierra Wireless MC8705, HSPA+ Release 7
- HSPA+ bands: 850, 900, 1900 and 2100 MHz
- HSPA+ speeds: up to 21 Mbps downlink, 5.76 Mbps uplink
- SIM slots: 2 internal (dual SIM)
- Wi-Fi: Dual-radio 802.11a/b/g/n, 2x3 MIMO, up to 300 Mbps PHY rate
- WAN: 1x 10/100/1000 Gigabit Ethernet, Cisco Smart Serial, cellular
- LAN: 4x 10/100 Fast Ethernet
- Console/auxiliary: 1x RJ-45
- Mini-USB: remote 3G diagnostics and monitoring
- DRAM: 1 GB
- Flash: 1 GB
- VLANs: 8x 802.1Q
- IPsec tunnels: 20
- Dimensions (H x W x D): 44 x 186 x 229 mm
- Weight: 1.54 kg
- Maximum platform power: 20 W
- AC adapter input: 85-264 VAC (100-240 VAC nominal)
- Operating temperature: -25 to 60 C
- Humidity: up to 95% non-condensing
- Ingress rating: IP41
- Minimum software: Cisco IOS 15.2(4)M1 or later
FAQs
Q: What cellular technology does it support?
A: It has an embedded HSPA+ Release 7 modem on 850, 900, 1900 and 2100 MHz, with fallback to HSDPA, UMTS, EDGE and GPRS.
Q: How is it powered?
A: It uses an external AC adapter (PWR2-20W-AC) supplying up to 20 W from 100-240 VAC. Optional 12 VDC and 24 VDC adapters (PWR2-20W-12VDC, PWR2-20W-24VDC) suit vehicle installations.
Q: Which software does it require?
A: It needs Cisco IOS Software 15.2(4)M1 or later. Optional software licences and subscription content filtering are available separately.
Q: Which serial cables work with the Smart Serial port?
A: It supports the Cisco Smart Serial cables CAB-SS-V35MT/FC, 232MT/FC, 449MT/FC, X21MT/FC, 530MT and 530AMT.
Q: How does this SKU differ from other 819 variants?
A: This is the hardened model with HSPA+ Release 7, 3G plus dual-band Wi-Fi, and the ANZ regulatory domain.
