Cisco

Cisco C1300X-48T-4X | Catalyst 1300X 48-Port Gigabit Switch, 4x SFP28, Layer 3

SKU:C1300X-48T-4X

$1,819.00 USD
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Catalyst 1300X is a fixed, managed Layer 3 switch built for small and medium-sized business networks and enterprise branch offices. It suits access or aggregation roles where static and dynamic routing, OSPF and stacking are required, and its compact design allows deployment outside the wiring closet, for example in retail.

This non-PoE model provides 48 Gigabit Ethernet RJ-45 ports and 4 SFP28 uplink ports running at 10G, with 25G available for stacking only. Switching capacity is 176 Gbps at wire speed and non-blocking, with a forwarding rate of 130.95 Mpps. Front Panel Stacking supports up to 8 switches from the same C1300X family, managed as a single unit with one IP address. The switch uses an internal 100-240V AC power supply and draws 66.7 W at 110V.

The SFP28 ports accept genuine Cisco SFP and SFP+ modules including MGBSX1, MGBLX1, MGBLH1, GLC-SX-MMD, GLC-LH-SMD, SFP-10G-SR, SFP-10G-LR, SFP-10G-ER and SFP-10G-T-X, as well as SFP-H10GB-CU twinax and SFP-10G-AOC cables. Management is through the Cisco Business Dashboard and the Cisco Business mobile app.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Static and dynamic Layer 3 routing, including OSPFv2/v3
- Front Panel Stacking for up to 8 switches managed as a single unit with one IP address
- Unified data, control and management plane across the stack with fast stack failover and LAG across stack members
- IPv4 and IPv6 support
- Managed through the Cisco Business Dashboard and Cisco Business mobile app
- Security features including SSH, SSL, 802.1X, port security, RADIUS/TACACS+ and ACLs
- Compact design suitable for deployment outside the wiring closet

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Datasheet

Technical Specifications

- Downlink ports: 48 x Gigabit Ethernet (10/100/1000) RJ-45
- Uplink ports: 4 x SFP28 (10G uplink, 25G available for stacking only)
- PoE: Not supported
- Switching capacity: 176 Gbps, wire speed and non-blocking
- Forwarding rate: 130.95 Mpps (64-byte packets)
- Console: Cisco standard RJ-45 console port and USB Type C port
- Flash: 1GB SLC
- CPU: ARM dual-core at 1.5 GHz
- DRAM: 2 GB DDR4
- Packet buffer: 3 MB
- MAC table: up to 32,000 entries
- Jumbo frames: up to 9000 bytes
- ACLs: up to 3072 rules
- IPv4 routes: up to 7168 (dynamic and static), up to 256 IP interfaces
- Stacking: Front Panel Stacking, up to 8 units, same family only
- Input voltage: 100-240V, 50-60 Hz (internal power supply)
- System power consumption: 66.7 W at 110V, 72.1 W at 220V
- Heat dissipation: 285.6 BTU/hr
- Dimensions (W x D x H): 444.3 x 270 x 43.94 mm
- Weight: 3.6 kg
- Acoustic noise: 21.6 dBA at 25 C with 1 fan
- Operating temperature: -5 to 50 C
- Storage temperature: -25 to 70 C
- Humidity: 10% to 90% relative, noncondensing
- Certifications: UL 62368, CSA 22.2, CE mark, FCC Part 15 Class A

FAQs

Q: Does this switch support PoE?
A: No. This is a non-PoE model, so the 48 Gigabit ports do not supply power to connected devices.

Q: Does it need a licence or subscription to operate?
A: No licence or subscription is required for operation. Layer 3 routing, OSPF and stacking are built into the switch.

Q: Which SFP modules and cables work in the SFP28 uplinks?
A: The uplinks support Cisco SFP and SFP+ modules such as MGBSX1, MGBLX1, MGBLH1, GLC-SX-MMD, GLC-LH-SMD, SFP-10G-SR, SFP-10G-LR, SFP-10G-ER and SFP-10G-T-X, plus SFP-H10GB-CU twinax and SFP-10G-AOC cables. They run at 10G for uplink use.

Q: Which switches can it be stacked with?
A: It stacks with up to 8 units from the C1300X family only, such as C1300X-24T-4X, C1300X-48P-4X and C1300X-48NGU-4X. Cross-family stacking with the C1300 series is not supported.

Q: How is the switch managed?
A: It is managed through the Cisco Business Dashboard and the Cisco Business mobile app, with a console available over the RJ-45 or USB Type C port.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
