Cisco C1300X-24T-4X | Catalyst 1300X 24-Port Gigabit Switch, 4x 10G SFP+

SKU:C1300X-24T-4X

$1,160.00 USD
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Cisco Catalyst 1300X 24-port Gigabit switch is a fixed, managed Layer 3 switch for branch offices and growing SMB networks. It suits secure office connectivity, unified communications with voice, data and video on one network, and guest access segmented by VLAN. Its compact design also allows deployment outside the wiring closet, such as in retail stores, open-plan offices and classrooms.

This non-PoE model provides 24 x 10/100/1000 RJ-45 ports and 4 x SFP28 ports that run at 10G for uplinks, with 25G available for stacking only. Switching capacity is 128 Gbps with a forwarding rate of 95.23 Mpps in a wire-speed, non-blocking design. Layer 3 routing covers static routes, RIPv2 and OSPF v2/v3, and up to 8 units can be joined through front panel stacking. Management is through the Cisco Business Dashboard, the Cisco Business mobile app, a web UI or the CLI.

The SFP28 ports accept 10G SFP+ and 1G SFP modules, including SFP-10G-SR, SFP-10G-LR and SFP-10G-ER, as well as 10G DAC and AOC cables. Stacking is supported with other Catalyst 1300X models only.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Dynamic Layer 3 routing with static routes, RIPv2 and OSPF v2/v3
- Front panel stacking of up to 8 switches managed as a single unit with one IP address
- Managed via Cisco Business Dashboard, the Cisco Business mobile app, web UI or CLI
- Cisco Network Plug and Play agent for near-zero-touch deployment
- Security including 802.1X, DHCP snooping, IP Source Guard, Dynamic ARP Inspection, port security and ACLs
- IPv4 and IPv6 dual stack support
- Energy Efficient Ethernet (IEEE 802.3az) with energy detect and time-based port operation
- Dual firmware images for resilient upgrades

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Datasheet

Technical Specifications

- Model: C1300X-24T-4X
- RJ-45 ports: 24 x 10/100/1000 Gigabit Ethernet
- Uplink ports: 4 x SFP28 (10G uplink, 25G for stacking only)
- PoE: Non-PoE model
- Switching capacity: 128 Gbps
- Forwarding rate: 95.23 Mpps (64-byte packets)
- Architecture: Wire-speed, non-blocking
- Packet buffer: 3 MB
- DRAM: 2 GB DDR4
- Flash: 1 GB
- CPU: ARM dual-core, 1.5 GHz
- MAC table: up to 32,000 entries
- IPv4 routes: up to 7,168 and up to 256 IP interfaces
- ACL rules: up to 3,072
- VLANs: up to 4094
- Link aggregation: up to 8 groups, 8 ports per group (LACP)
- Jumbo frames: up to 9000 bytes
- Stacking: up to 8 units, up to 400 ports
- Console: RJ-45 console port and USB Type-C port
- Power supply: 100-240 V AC, 50-60 Hz, internal
- Power consumption (worst case): 31.7 W at 110 V, 32.1 W at 220 V
- Dimensions (W x D x H): 444.3 x 270 x 43.94 mm
- Weight: 3.28 kg
- Operating temperature: -5 to 50 C
- Form factor: 1U rack-mountable

FAQs

Q: Does this switch need a separate licence or subscription?
A: No separate licence or subscription is specified for this model. It can be managed through the Cisco Business Dashboard, the Cisco Business mobile app, the web UI or the CLI.

Q: Does this switch provide PoE?
A: No. The 24 RJ-45 ports are non-PoE, so there is no PoE budget. It runs from an internal 100-240 V AC, 50-60 Hz power supply.

Q: What can be installed in the SFP28 ports?
A: The four SFP28 ports support 10G SFP+ and 1G SFP modules, including SFP-10G-SR, SFP-10G-LR and SFP-10G-ER, as well as 10G DAC and AOC cables. 25G modules and cables are also supported, with 25G speed available for stacking only.

Q: Can it be stacked with other switches?
A: Yes. Up to 8 units can be stacked using the front panel SFP28 ports. Stacking is supported with other Catalyst 1300X models only, not with Catalyst 1300 models.

Q: Does it support dynamic Layer 3 routing?
A: Yes. It supports static routing, RIPv2 and OSPF v2/v3, with OSPF available on the 1300X models.
