Cisco C1300X-24MU-4X | Catalyst 1300X 24-Port 2.5G PoE++ Switch, 740W, 4x SFP28
SKU:C1300X-24MU-4X
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The Catalyst 1300X is a fixed, managed Layer 3 multigigabit switch for small and mid-sized branch offices and SMB networks. It suits secure office connectivity, unified communications and Wi-Fi 7 access point deployments that need 2.5G ports with 60W PoE++, as well as growing networks that need Layer 3 routing and stacking.
This model provides 24 x 2.5G mGig RJ-45 ports, made up of 16 ports at 30W PoE+ and 8 ports at 60W PoE++, sharing a 740W PoE budget. Four SFP28 ports provide 10G uplinks, with 25G available for stacking only. Switching capacity is 200 Gbps with a 148.80 mpps forwarding rate. Layer 3 features include OSPFv2/v3 and RIPv2, and front-panel stacking supports up to 8 units managed as one.
The SFP28 ports accept supported 10G SFP+ and 10/25G optics, DACs and AOCs, such as SFP-10G-SR, SFP-10G-LR, SFP-10G-T-X and SFP-H10GB-CU cables. Stacking is limited to other C1300X family switches. No licence or subscription is required to operate the switch.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Layer 3 routing with OSPFv2/v3, RIPv2 and policy-based routing
- Front-panel stacking of up to 8 switches managed as a single unit with one IP address
- Managed via Cisco Business Dashboard, Cisco Business mobile app, web GUI, CLI and SNMP
- Cisco Network Plug and Play support for near-zero-touch deployment
- Security features including 802.1X, port security, DHCP snooping, IP Source Guard, Dynamic ARP Inspection and IPv6 First Hop Security
- QoS with 8 hardware queues, strict priority and WRR scheduling
- Energy efficiency with IEEE 802.3az EEE, time-based port and PoE, and persistent PoE
- Dual firmware images for resilient upgrades
- USB Type-C and RJ-45 console ports, with Bluetooth dongle support for wireless console access
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Ports: 24 x 2.5G mGig RJ-45 plus 4 x SFP28
- PoE ports: 16 x 2.5G at 30W PoE+ and 8 x 2.5G at 60W PoE++
- PoE standards: 802.3at PoE+ and 802.3bt PoE++
- PoE power budget: 740W across 24 ports
- Uplinks: 4 x SFP28, 10G uplink, 25G for stacking only
- Switching capacity: 200 Gbps
- Forwarding rate (64-byte packets): 148.80 mpps
- Packet buffer: 3 MB
- CPU / DRAM / Flash: ARM dual-core 1.5 GHz / 2 GB DDR4 / 1 GB SLC
- MAC table: up to 32,000 entries
- IPv4 routing: up to 7168 routes and 256 IP interfaces
- ACL: up to 3072 rules
- VLANs: up to 4094
- IGMP multicast groups: 4000
- Jumbo frames: up to 9000 bytes
- Stacking: up to 8 units, up to 400 ports
- Power supply: internal universal AC, 100-240V 50-60 Hz
- Power consumption without PoE: 92 W at 110V, 86.2 W at 220V
- Power consumption with PoE: 870.4 W at 110V, 866.5 W at 220V
- Heat dissipation: 2989.04 BTU/hr
- Dimensions (W x D x H): 444.3 x 270 x 43.94 mm, 1RU
- Weight: 4.28 kg
- Operating temperature: -5 to 50 C
- Storage temperature: -25 to 70 C
- Acoustic noise: 47.9 dBA at 25 C, 1 fan
- MTBF at 25 C: 321,420 hours
- Certifications: UL 62368, CSA 22.2, CE, FCC Part 15 Class A
FAQs
Q: Does the C1300X-24MU-4X need a licence or subscription?
A: No. The switch operates without a licence or subscription, and its Layer 3 features are available out of the box.
Q: How is the PoE budget split across the ports?
A: The 740W PoE budget is shared across 24 ports. 16 ports provide up to 30W PoE+ and 8 ports provide up to 60W PoE++ (802.3bt).
Q: What speed do the SFP28 ports run at?
A: The four SFP28 ports run at 10G for uplinks. 25G is available for stacking only.
Q: Which optics and cables work in the SFP28 ports?
A: Supported options include SFP-10G-SR, SFP-10G-LR, SFP-10G-ER, SFP-10G-T-X, SFP-H10GB-CU1M/3M/5M, SFP-10G-AOC cables, SFP-25G-AOC cables, SFP-H25G-CU cables, SFP-10/25G-CSR-S and SFP-10/25G-LR-S.
Q: Which switches can it stack with?
A: It stacks only with other Catalyst 1300X family switches, up to 8 units. Cross-stacking with Catalyst 1300 models is not supported.
Q: How does it differ from the other C1300X models?
A: This model has 24 x 2.5G mGig ports with 8 x 60W PoE++ ports, a 740W PoE budget and 4 x SFP28 uplinks, so it suits Wi-Fi 7 access point deployments.
