Cisco AIR-AP2802E-Z-K9 | Aironet 2802e Wi-Fi 5 Access Point, External Antennas, Z Domain

AIR-AP2802E-Z-K9

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Aironet 2802e is an indoor dual-band 802.11ac Wave 2 controller-based access point from the Cisco Aironet 2800 Series. The "e" model uses external antennas, which suits warehouses, auditoriums, convention centres, libraries, cafeterias and stadiums where directional or specialised antennas are needed.

It uses 4x4 MU-MIMO with three spatial streams and a flexible radio that can run as a 2.4 GHz or 5 GHz radio alongside a dedicated 5 GHz radio. In dual 5 GHz mode it delivers up to 5.2 Gbps over the air (2 x 2.6 Gbps), with 20/40/80/160 MHz channel support. Two 100/1000BASE-T RJ-45 ports support auto link aggregation. This SKU is configured for the Z regulatory domain, which includes Australia. It runs on 802.3at PoE+, Cisco UPOE or an AIR-PWRINJ6= injector, with a draw of 20 W at the powered device.

It joins Cisco Catalyst 9800 Series, 2500, 3500, 5500 and 8500 Series controllers, Flex 7500, the Virtual Wireless Controller and integrated Catalyst 3850 and 3650 controllers, and also runs in Mobility Express mode. External antennas use RP-TNC connectors and are sold separately.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- 802.11ac Wave 2 with a theoretical rate of up to 2.6 Gbps per radio
- MU-MIMO with three spatial streams to share streams between clients
- Flexible Radio Assignment: 2.4/5 GHz, dual 5 GHz, or security monitoring plus 5 GHz
- Smart antenna connector allows two antenna sets to be active on one access point
- 160 MHz channel support with Dynamic Bandwidth Selection
- High Density Experience (HDX) with CleanAir, ClientLink 4.0 and optimised roaming
- Auto link aggregation (802.3ad LACP) across both Gigabit Ethernet ports
- Cisco Mobility Express mode for controller-less deployments of up to 100 access points
- Can operate as an OfficeExtend Access Point (OEAP) for remote workers

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Wireless standard: 802.11a/b/g/n/ac Wave 2
- Radios: dual-band, flexible radio (2.4 GHz or 5 GHz) plus dedicated 5 GHz radio
- MIMO: 4x4 MU-MIMO with 3 spatial streams
- Maximum over-the-air rate: up to 5.2 Gbps (2 x 2.6 Gbps in dual 5 GHz mode)
- Channel widths: 20/40/80/160 MHz
- Ethernet ports: 2 x 100/1000BASE-T (RJ-45) autosensing
- Management: RJ-45 console port, USB 2.0
- Antennas: external, RP-TNC connectors, plus smart antenna connector
- Certified antenna gain: up to 6 dBi (2.4 GHz and 5 GHz)
- Transmit power: 23 dBm (200 mW) down to 2 dBm in 3 dB steps
- Power input: 802.3at PoE+, Cisco UPOE or AIR-PWRINJ6= injector
- Power draw: 22.5 W at the PSE (20 W at the PD); 26.5 W at the PSE (23 W at the PD) with USB 2.0 enabled
- Memory: 1024 MB DRAM, 256 MB flash
- Dimensions (W x L x H): 8.66 x 8.77 x 2.50 in, without mounting brackets
- Weight: 4.6 lb (2.09 kg)
- Operating temperature: -20 to 50 C
- Storage temperature: -30 to 70 C
- Operating humidity: 10% to 90% (noncondensing)
- Regulatory domain: Z
- Security: 802.11i, WPA3, WPA2, WPA, 802.1X, AES

FAQs

Q: Does this access point need a licence or subscription?
A: A Cisco DNA subscription (Essentials or Advantage) is required for the access point to join a Cisco Catalyst 9800 Series controller. These subscriptions include perpetual Network Essentials or Network Advantage rights. The hardware SKU itself does not include a DNA subscription.

Q: How is the AIR-AP2802E-Z-K9 powered?
A: It runs from 802.3at PoE+, Cisco UPOE or an AIR-PWRINJ6= power injector. Power draw is 22.5 W at the switch port (20 W at the access point), rising to 26.5 W at the switch port with USB 2.0 enabled.

Q: Which controllers does it work with?
A: It works with Cisco 2500, 3500, 5500 and 8500 Series controllers, Flex 7500, Catalyst 9800 Series, the Virtual Wireless Controller, WiSM2, the ISR G2 controller module and the integrated controllers in Catalyst 3850 and 3650 switches. It also supports Mobility Express.

Q: Which antennas does it use?
A: It uses external antennas with RP-TNC connectors, certified for gains up to 6 dBi on both 2.4 GHz and 5 GHz. The AIR-CAB002-DART-R= cable connects a second antenna to the smart antenna connector.

Q: What does the Z regulatory domain mean?
A: The Z domain covers Australia and sets the permitted channels and power levels. This SKU supports 2.412 to 2.462 GHz and the 5 GHz bands from 5.180 to 5.825 GHz, excluding 5.600 to 5.640 GHz.
