• Cisco AIR-AP1815M-Z-K9 Wi-Fi 5 access point with blue logo
1 1

Cisco

Cisco AIR-AP1815M-Z-K9 | Aironet 1815m Wi-Fi 5 Dual-Band Access Point, Z Domain

AIR-AP1815M-Z-K9

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Aironet 1815m is an indoor 802.11ac Wave 2 (Wi-Fi 5) access point built for dense buildings such as hotels and dorm rooms. It runs two radios on 2.4 GHz and 5 GHz with 2x2 MU-MIMO and two spatial streams, and offers higher transmit power than the other 1815 models to carry signal through walls and doors. It can also act as an Office Extend Access Point for remote workers and micro-offices.

This SKU is the Regulatory Domain Z, controller-based K9 variant. It delivers up to 866.7 Mbps on 5 GHz with 80 MHz channels, with a maximum transmit power of 27 dBm on 2.4 GHz and 24 dBm on 5 GHz. A single 10/100/1000BASE-T RJ-45 port is powered by 802.3af or 802.3at PoE, with a maximum draw of 13.9 W. Each radio supports up to 200 clients, for 400 per access point. Cisco DNA subscription licensing is required to join a Catalyst 9800 Series Wireless Controller, and the Z domain channel plan applies.

It joins Cisco AireOS controllers (2500, 3500, 5500, 8500 and Flex 7500 Series, WiSM2 and the ISR G2 controller module) running release 8.5.103 or later, as well as the Catalyst 9800 Series.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- 802.11ac Wave 2 with MU-MIMO for simultaneous transmission to multiple clients
- Higher transmit power than other 1815 models to penetrate walls and doors in dense buildings
- Can act as an Office Extend Access Point (OEAP) for remote workers
- Integrated Bluetooth 4.1 / BLE for location and asset tracking applications
- Flexible wall or ceiling mounting in a small form factor
- Security support including WPA3, WPA2, 802.1X, 802.11i, 802.11r and AES
- Supports Cisco DNA Center features such as User Defined Network

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Wi-Fi standard: IEEE 802.11a/b/g/n/ac Wave 2 (also 802.11h, 802.11d)
- Bands: dual-band, 2.4 GHz and 5 GHz
- MIMO: 2 x 2 single-user/multiuser MIMO with two spatial streams
- Channel widths: 20, 40 and 80 MHz
- PHY data rate: up to 866.7 Mbps (80 MHz on 5 GHz)
- Maximum clients: 200 per radio, 400 per access point
- Regulatory domain: Z
- Z domain channels: 2.412-2.462 GHz (11 channels); 5.180-5.320 GHz (8 channels); 5.500-5.700 GHz (8 channels, excludes 5.600-5.640 GHz); 5.745-5.825 GHz (5 channels)
- Transmit power 2.4 GHz: 27 dBm (500 mW) max, adjustable down to 6 dBm (4 mW)
- Transmit power 5 GHz: 24 dBm (250 mW) max, adjustable down to 3 dBm (2 mW)
- Integrated antennas: 2 dBi (2.4 GHz), 4 dBi (5 GHz)
- Bluetooth: integrated Bluetooth 4.1 (BLE), 4 dBm max transmit power, 2 dBi antenna gain
- Interfaces: 1 x 10/100/1000BASE-T autosensing (RJ-45) with PoE; management console port (RJ-45)
- PoE input: 802.3af or 802.3at
- Power draw: max 13.9 W with 100 m Category 5 cable
- System memory: 1 GB DRAM, 256 MB flash, 710 MHz quad-core
- Dimensions (W x L x H): 150.8 x 150.8 x 33 mm
- Weight: 460 g
- Operating temperature: 0 to 40 C
- Operating humidity: 10% to 90% non-condensing
- Storage temperature: -30 to 70 C
- Software: AireOS Wireless Controller release 8.5.103 or later

FAQs

Q: Does this access point need a licence or subscription?
A: A Cisco DNA software subscription (Essentials or Advantage, in 3, 5 or 7-year terms) is required to connect it to a Catalyst 9800 Series Wireless Controller. Perpetual Network Essentials and Network Advantage features remain after the term ends.

Q: How is the AIR-AP1815M-Z-K9 powered?
A: It is powered over Ethernet using 802.3af or 802.3at on its single RJ-45 port, with a maximum draw of 13.9 W. Cisco power injectors AIR-PWRINJ5= and AIR-PWRINJ6= are optional.

Q: Which controllers does it work with?
A: It works with Cisco 2500, 3500, 5500, 8500 and Flex 7500 Series controllers, WiSM2, the Wireless Controller Module for ISR G2, and the Catalyst 9800 Series. AireOS release 8.5.103 or later is required.

Q: What is the difference between the K9 and K9C versions?
A: AIR-AP1815M-Z-K9 is the controller-based image. The Mobility Express default image is supplied on the separate -K9C SKU.

Q: What does the Z regulatory domain mean?
A: The Z domain sets the permitted channels and power levels for the region. This SKU covers 2.412-2.462 GHz, 5.180-5.320 GHz, 5.500-5.700 GHz (excluding 5.600-5.640 GHz) and 5.745-5.825 GHz.
