Aruba R8Q72A | CX 6200F 12-Port PoE+ Switch, 139W, 2x 10G SFP+
SKU:R8Q72A
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The Aruba CX 6200F is a fanless, fixed-configuration 1U Layer 2/3 access switch for branch offices, campus access layers and SMB networks. With 12 Class 4 PoE ports it can power IoT devices, cameras and wireless access points at the network edge, and it runs the AOS-CX operating system.
This SKU provides 12 x 10/100/1000BASE-T PoE ports at up to 30W per port from a 139W PoE budget (IEEE 802.3af/802.3at). Uplinks are 2 x 100M/1G RJ45 ports and 2 x 1G/10G SFP/SFP+ ports. Switching capacity is 68 Gbps with forwarding of up to 45.1 Mpps. It is powered by a fixed internal AC supply and draws 23W idle and 28W at full traffic load at 230 VAC. Being fanless, it is silent in operation.
VSF stacking supports up to 8 members with up to 20 Gbps of stacking bandwidth, but only between 12-port 6200F units. The 10G uplinks accept Aruba 10G SFP+ DAC cables such as J9281D and J9283D.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- AOS-CX database-driven operating system with REST APIs and Python scripting
- Network Analytics Engine (NAE) for automated monitoring and troubleshooting
- Managed through Aruba Central (cloud or on-premises) or the CX Mobile App
- VSF stacking for simple scale-out across 12-port 6200F units
- Dynamic Segmentation extends role-based policy to wired access
- Layer 3 with static routing, OSPF and OSPFv3 for IPv6
- Always-on PoE and Quick PoE
- Energy Efficient Ethernet (IEEE 802.3az)
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Ports: 12 x 10/100/1000BASE-T Class 4 PoE, up to 30W per port
- Uplinks: 2 x 100M/1G RJ45 and 2 x 1G/10G SFP/SFP+ (PHY-less)
- PoE budget: 139W (IEEE 802.3af/802.3at)
- Switching capacity: 68 Gbps
- Throughput: up to 45.1 Mpps
- Stacking: VSF, up to 8 members (12-port 6200F only), up to 20 Gbps
- Management ports: 1x RJ-45 console, 1x USB-C console, 1x OOBM, 1x USB Type-A host
- CPU: Quad Core ARM Cortex A72 at 1.2GHz
- Memory and flash: 8 GB DDR4, 16 GB eMMC
- Packet buffer: 8 MB total
- MAC table capacity: 32,768
- IPv4 / IPv6 unicast routes: 2,048 / 1,024
- Power supply: fixed internal AC, 90-264 VAC, 50/60 Hz
- Power consumption (230 VAC): 23W idle, 28W at 100% traffic
- Cooling: fanless
- Dimensions (H x W x D): 4.39 x 25.4 x 30.5 cm
- Weight: 3.24 kg
- Operating temperature: 0 to 45 C up to 5,000 ft
- Operating humidity: 5% to 95% non-condensing
FAQs
Q: Does this switch need a licence to run?
A: AOS-CX runs on the switch without a separate licence. Aruba Central management needs a separate subscription, such as the Central Switch 6200/29xx Foundation licence in 1, 3 or 5 year terms.
Q: How much PoE power does it provide?
A: It provides up to 139W of total PoE power across 12 Class 4 ports, with up to 30W per port under IEEE 802.3af/802.3at.
Q: Can it stack with other 6200 switches?
A: VSF stacking supports up to 8 members, but only with other 12-port 6200F switches. It does not stack with 24 or 48-port 6200F or 6200M models.
Q: Which cables suit the 10G SFP+ uplinks?
A: The SFP/SFP+ uplinks accept Aruba 10G SFP+ DAC cables such as J9281D (1m) and J9283D (3m), as well as compatible SFP and SFP+ transceivers.
Q: Does it have a fan?
A: No. The switch is fanless, so it runs silently and suits offices and other noise-sensitive spaces.
