Aruba

Aruba R4W53A | AP-565 Wi-Fi 6 Outdoor Access Point, 2x2:2, RW, Omni

SKU:R4W53A

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The AP-565 is an entry-level, ruggedised outdoor Wi-Fi 6 (802.11ax) access point from the Aruba 560 Series. It is built for campuses, yards, warehouses and industrial or logistics sites that face high wind, temperature extremes and moisture, and it delivers medium-density coverage with integrated omni-directional antennas. This R4W53A is the Rest-of-World (RW) regulatory-domain, TAA-compliant model.

The access point has two software-configurable 2x2:2 radios, one for 5 GHz and one for 2.4 GHz, with a peak aggregate data rate of up to 1.49 Gbps. Built-in omni antennas provide 5.4 dBi on 5 GHz and 3.2 dBi on 2.4 GHz. A single 10/100/1000BASE-T RJ-45 port carries data and PoE, and a USB-C console port handles local management. Bluetooth 5 and 802.15.4 (Zigbee) IoT radios are integrated. The IP66/IP67 enclosure is rated for -40 to +55 C and wind survival up to 165 mph.

Power draw is a maximum of 15.6 W, 4.2 W idle and 1.7 W in deep sleep. It is powered by 802.3at (PoE+) without restriction, and 802.3af is supported with Intelligent Power Monitoring. It runs in controller mode with ArubaOS or controller-less Instant mode, and can be managed through Aruba Central, AirWave or a mobility controller. Mounting kits AP-270-MNT-V1, V2, H1, H2 and H3 are compatible.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Wi-Fi 6 OFDMA serves multiple clients per channel at once
- Target wake time (TWT) improves battery life of IoT devices
- WPA3 and Enhanced Open (OWE) encryption and authentication
- Policy Enforcement Firewall (PEF) with tunnelled end-to-end traffic encryption
- Installed trusted platform module (TPM) for device assurance
- Intelligent Power Monitoring (IPM) adapts AP capabilities to the available PoE budget
- Zero Touch Provisioning via Aruba Central or AirWave
- Transmit beamforming (TxBF), MRC, STBC and LDPC

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Wi-Fi standard: Wi-Fi 6 (802.11ax)
- Radios: dual radio, 5 GHz 2x2:2 MIMO and 2.4 GHz 2x2:2 MIMO
- Peak aggregate data rate: up to 1.49 Gbps
- Antennas: built-in omni, 5 GHz 5.4 dBi, 2.4 GHz 3.2 dBi, BLE/802.15.4 3.3 dBi
- Maximum EIRP (2.4 GHz): 29.2 dBm, limited by local regulatory requirements
- Maximum EIRP (5 GHz): 31.4 dBm, limited by local regulatory requirements
- Network interface: 1 x 10/100/1000BASE-T (RJ-45), auto-sensing, PoE-PD
- Console: USB-C
- PoE: 802.3at (PoE+), 802.3at/bt Class 3 or higher, 48 Vdc nominal
- IoT radios: Bluetooth 5 and Zigbee/802.15.4
- Maximum power consumption: 15.6 W
- Idle power consumption: 4.2 W
- Deep-sleep power consumption: 1.7 W
- Dimensions (excluding mount): 16.5 x 16.5 x 13 cm
- Weight: 1.03 kg
- Operating temperature: -40 to +55 C
- Operating humidity: 5% to 95% non-condensing
- Storage and transport temperature: -40 to +70 C
- Operating altitude: 3,000 m
- Ingress protection: IP66/IP67
- Wind survival: up to 165 mph
- Minimum software: ArubaOS and Aruba InstantOS 8.7.1.0
- Regulatory domain: Rest-of-World (RW), TAA compliant

FAQs

Q: Does the AP-565 need a licence to operate?
A: No licence is required for the access point hardware itself. It runs in controller mode (ArubaOS) or controller-less Instant mode. Management through Aruba Central requires a separate subscription.

Q: What PoE standard does the AP-565 need?
A: It is powered through its E0 port by 802.3at (PoE+), which gives full, unrestricted operation. 802.3af is also supported with Intelligent Power Monitoring, which may restrict some features. Maximum draw is 15.6 W. Power injectors are sold separately.

Q: Which mounting kits work with the AP-565?
A: The compatible kits are AP-270-MNT-V1, AP-270-MNT-V2, AP-270-MNT-H1, AP-270-MNT-H2 and AP-270-MNT-H3, sold separately.

Q: How does this SKU differ from other AP-565 models?
A: The R4W53A is the Rest-of-World (RW) regulatory-domain model with integrated omni antennas and TAA compliance. Other AP-565 SKUs are built for different regulatory domains.

Q: What software does the AP-565 run?
A: It requires ArubaOS or Aruba InstantOS 8.7.1.0 or later. It can be managed by Aruba Central, AirWave or a mobility controller.
