Cisco UCS-CPU-8160 | Xeon Platinum 8160 24-Core 2.1GHz CPU, 150W, 33MB

UCS-CPU-8160

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Cisco UCS-CPU-8160 is an Intel Xeon Platinum 8160 (Skylake-SP) server processor from the Cisco UCS M5 CPU options range. It suits upgrade or replacement work on Cisco UCS M5 servers running virtualisation, database, analytics, HPC and other compute-intensive enterprise workloads.

The processor delivers 24 cores and 48 threads at a 2.1 GHz base frequency, with Turbo Boost 2.0 up to 3.7 GHz and 33 MB of L3 cache. It has a 150 W TDP, three UPI links at 10.4 GT/s, and six channels of DDR4-2666 memory supporting up to 768 GB per CPU. It provides 48 PCIe 3.0 lanes and AVX-512 instruction support with two FMA units, and uses the FCLGA3647 socket.

It is used in Cisco UCS M5 generation servers, including the UCS B200 M5 blade, UCS C220 M5 and C240 M5 rack servers, and the UCS C480 M5. It pairs with DDR4-2666 DIMMs and does not support Optane DC persistent memory. For UCS Manager, Cisco recommends releases that support higher-wattage CPUs, such as UCSM 3.2(2) or 4.0 for the B200 M5.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Top-bin 24-core Intel Xeon Platinum (Skylake-SP) processor for dense, compute-intensive workloads
- Intel Hyper-Threading and Turbo Boost 2.0 up to 3.7 GHz
- AVX-512 instruction support with two FMA units for HPC and analytics acceleration
- Six-channel DDR4-2666 memory with up to 768 GB per socket
- Scalable to 8 sockets (S8S) over 3 UPI links
- Intel Speed Shift Technology, Intel VMD and Intel TSX support

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Processor: Intel Xeon Platinum 8160
- Product collection: Intel Xeon Scalable Processors (formerly Skylake)
- Cisco description: 2.1 GHz 8160/150W 24C/33MB Cache/DDR4 2666MHz
- Lithography: 14 nm
- Cores / threads: 24 / 48
- Base frequency: 2.10 GHz
- Max turbo frequency: 3.70 GHz
- Cache: 33 MB L3
- TDP: 150 W
- UPI links: 3 at 10.4 GT/s
- Memory type: DDR4-2666, 6 channels
- Max memory size: 768 GB per CPU
- ECC memory supported: Yes
- Scalability: S8S (up to 8 sockets)
- PCI Express: revision 3.0, up to 48 lanes
- Socket: FCLGA3647 (LGA 3647)
- T-case: 85 C
- Package size: 76.0 mm x 56.5 mm
- Instruction set extensions: SSE4.2, AVX, AVX2, AVX-512 (2 FMA units)
- Optane DC persistent memory supported: No

FAQs

Q: Which Cisco servers use this processor?
A: It is a CPU option for Cisco UCS M5 generation servers, including the UCS B200 M5 blade, UCS C220 M5 and C240 M5 rack servers, and the UCS C480 M5.

Q: Does it support Intel Optane DC persistent memory?
A: No. The Xeon Platinum 8160 does not support Optane DC persistent memory. It pairs with DDR4-2666 DIMMs across six memory channels.

Q: What power and cooling does it need?
A: It has a 150 W TDP per processor. Power supply and cooling requirements depend on the host UCS server and how many CPUs are fitted.

Q: Which UCS Manager release is recommended?
A: Cisco recommends UCS Manager releases that support higher-wattage CPUs, such as UCSM 3.2(2) or 4.0 for the B200 M5.

Q: How much memory can each processor address?
A: The standard Xeon Platinum 8160 supports up to 768 GB of memory per CPU. The M variant, which supports 1.5 TB, is a different part.
