NVIDIA

NVIDIA 930-9DHAR-0001-000 | BlueField-3 150mm Gen 5.0 PCIe Harness, 60-pin

930-9DHAR-0001-000

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This 150 mm Cabline CA-II Plus micro-coax harness is a field-replaceable (FRU) spare for NVIDIA BlueField-3 DPUs. It connects the DPU to a PCIe x16 auxiliary connection card and is intended for servicing or replacing the harness in a BlueField-3 PCIe auxiliary kit.

The harness uses 60-pin Cabline CA-II Plus connectors with 38 AWG micro coax and supports PCIe Gen 5.0, with Gen 4.0 operation also supported on the auxiliary card. Being passive, it draws no power of its own. This is the 150 mm Gen 5.0 length, matching the harnesses used in kit 930-9DAX5-0015-000. The 250 mm and 350 mm harnesses in other kits are Gen 4.0 only, so choose this length when you need Gen 5.0 operation.

It works with BlueField-3 B3220, B3240, B3210 and B3210E DPUs. Typical deployments are dual-socket servers using the Socket Direct option, or downstream port (DSP) extension for storage devices. The auxiliary card kits use two harnesses with different routings, black for the component side and white for the print side of the network card.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Connects a BlueField-3 DPU to a PCIe x16 auxiliary connection card
- Supports the Down Stream Port (DSP) extension option for storage devices
- Supports the Socket Direct option for dual-socket servers
- PCIe Gen 5.0 capable with 38 AWG micro-coax construction
- Single 150 mm spare harness, replaceable in the field
- Matches the 150 mm harnesses used in kit 930-9DAX5-0015-000

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Length: 150 mm (15 cm)
- Harness type: Cabline CA-II Plus, 60-pin
- Wire type and gauge: micro coax, 38 AWG
- Connector mating: 60-pin connectors, P/N 20790-060E-01, on both ends
- PCIe interface: PCIe Gen 5.0 supported (16/32 GT/s SERDES, x16 lanes, Gen 3.0 compatible)
- Applicable DPU models: B3220, B3240, B3210, B3210E
- Form: field-replaceable harness (FRU)
- Power: passive harness, no power draw of its own
- Auxiliary card size (in kits): 129.30 mm x 59.00 mm (5.09 in x 2.32 in)
- Auxiliary card power (in kits): 12 V and 3.3V_AUX, max 100 mA on 3.3V_AUX
- Auxiliary card operating temperature (in kits): 0 to 55 C

FAQs

Q: Which BlueField-3 DPUs does this harness work with?
A: It works with BlueField-3 B3220, B3240, B3210 and B3210E DPUs, together with the PCIe x16 auxiliary connection card.

Q: Does this harness support PCIe Gen 5.0?
A: Yes. The 150 mm Cabline CA-II Plus harness supports PCIe Gen 5.0, and the auxiliary card also runs at Gen 4.0 speeds. The 250 mm and 350 mm harnesses in other kits are Gen 4.0 only.

Q: Which kits use the 150 mm Gen 5.0 harness?
A: The 150 mm Gen 5.0 harnesses are used in kit 930-9DAX5-0015-000 for the Down Stream Port option and MTMK9100-T15 for Socket Direct. This part is the spare harness for those kits.

Q: Does the harness need its own power?
A: No. It is a passive harness with no power draw of its own. The associated auxiliary card is powered from 12 V and 3.3V_AUX.

Q: Why do the auxiliary kits use two harnesses?
A: The two harnesses have different routings. The black harness mates with the component (top) side of the network card and the white harness with the print (bottom) side.
