NVIDIA 900-9X81E-00EX-SL0 | ConnectX-8 C8180L 800G XDR IB SuperNIC, SocketDirect
SKU:900-9X81E-00EX-SL0
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The NVIDIA ConnectX-8 C8180L is a half-height, half-length SuperNIC for AI and HPC clusters that need high-bandwidth, low-latency links between compute nodes and switches. A single OSFP cage runs 800Gb/s XDR InfiniBand by default or 2x400GbE Ethernet.
This SKU is the C8180L Partner Cooled variant with SocketDirect and TCXO timing. It connects to the host over PCIe 6 x16, with an x16 PCIe SocketDirect extension option, and relies on host system airflow for cooling. Precision timing covers IEEE 1588 PTP, PTM, TCXO, SyncE and two PPS in/out signals, while inline crypto and Secure Boot are supported. It ships with a tall bracket.
It works with NVIDIA LinkX XDR InfiniBand and 400GbE cables and transceivers. Host software support includes DOCA-Host, WinOF-2 for Windows and the MFT firmware tools. PPS In/Out is exposed through the 930-9XCBL-000A-000 extender.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- 800Gb/s XDR InfiniBand by default, or 2x400GbE Ethernet, from a single OSFP cage
- PCIe 6 x16 host interface
- Inline crypto and Secure Boot
- Precision timing with IEEE 1588 PTP, PTM, TCXO, SyncE and two PPS in/out signals
- SocketDirect x16 PCIe extension option
- Partner-cooled design, with cooling provided by the host system
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Model: C8180L (Partner Cooled)
- NVIDIA SKU: 900-9X81E-00EX-SL0
- Port type: Single-cage OSFP
- InfiniBand speed: 800Gb/s XDR IB (default)
- Ethernet speed: 2x400GbE
- Form factor: Half-Height, Half-Length (HHHL)
- PCI Express: PCIe 6 x16
- Extension option: x16 PCIe SocketDirect
- Crypto: Supported
- Secure Boot: Supported
- Timing: IEEE 1588 PTP, PTM, TCXO, PPS In/Out (2), SyncE
- Bracket type: Tall bracket
- Lifecycle: Mass Production
FAQs
Q: How does this SKU differ from the -ST0 and -DT0 versions?
A: The -SL0 is the C8180L Partner Cooled variant with SocketDirect and TCXO timing. The -ST0 is the C8180 SocketDirect and the -DT0 is the C8180 Down Stream Port.
Q: What does Partner Cooled mean for installation?
A: The C8180L relies on airflow from the host system, so the server or chassis must provide the cooling for the card.
Q: Can the OSFP port run Ethernet as well as InfiniBand?
A: Yes. The single OSFP cage runs 800Gb/s XDR InfiniBand by default or can be configured for 2x400GbE Ethernet.
Q: Which cables and transceivers does it work with?
A: It works with NVIDIA LinkX XDR InfiniBand and 400GbE cables and transceivers.
Q: How do I use the PPS In/Out signals?
A: PPS In/Out is exposed through the 930-9XCBL-000A-000 cable extender.
