NVIDIA 900-9X6AF-0018-MT0 | ConnectX-6 VPI Network Adapter, 200Gb/s HDR, QSFP56
SKU:900-9X6AF-0018-MT0
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The ConnectX-6 VPI is a single-port PCIe 4.0 x16 adapter card that runs either HDR 200Gb/s InfiniBand or 200GbE through one QSFP56 cage. It is built for HPC clusters, AI and machine learning training fabrics, high-performance storage using NVMe-oF and RDMA, and cloud or data-centre servers that need 200Gb/s connectivity.
This variant has a single QSFP56 port that supports copper and optical cabling, with a tall bracket fitted. InfiniBand speeds run from SDR through to HDR, including HDR100 and EDR, and Ethernet speeds cover 1, 10, 25, 40, 50, 100 and 200Gb/s. The host interface is PCIe Gen4 x16 and remains compatible with Gen3 slots. Typical power draw is 19.3W with passive cables, and the QSFP56 port can supply up to 5W to active cables or modules.
It works with QSFP56 HDR and 200GbE DAC, AOC and optical modules, and with lower-speed InfiniBand and 100, 50, 40, 25 and 10GbE links using compatible cables or breakouts. No software licence is required for the adapter itself.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Dual-protocol (VPI) operation: the port can run InfiniBand or Ethernet
- HDR 200Gb/s InfiniBand and 200GbE connectivity from a single QSFP56 port
- PCIe Gen4 x16 host interface, backward compatible with Gen3
- Backward compatible with lower InfiniBand speeds (SDR to HDR100) and Ethernet speeds down to 1GbE
- Supports copper and optical QSFP56 cabling, with up to 5W available at the port for active cables
- RDMA support for NVMe-oF storage and low-latency HPC and AI workloads
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Ports: 1 x QSFP56 (InfiniBand and Ethernet, copper and optical)
- InfiniBand speeds: SDR, DDR, QDR, FDR10, FDR, EDR, HDR100, HDR (up to 200Gb/s)
- Ethernet speeds: 1/10/25/40/50/100/200 Gb/s
- InfiniBand protocol: IBTA v1.4a
- Host interface: PCIe Gen3/Gen4 x16 (SERDES at 8.0GT/s and 16GT/s), 2.0 and 1.1 compatible
- Bracket: Tall
- Card size: 167.65 mm x 68.90 mm (6.6 in. x 2.71 in.)
- Typical power (passive cables): 19.3W
- Maximum power available through QSFP56 port: 5W
- Voltage: 3.3V aux, maximum current 100mA
- Airflow, passive cables: 350 LFM at 55 C (heatsink to port), 250 LFM at 35 C (port to heatsink)
- Airflow, NVIDIA active 4.7W cables: 500 LFM at 55 C (heatsink to port), 250 LFM at 35 C (port to heatsink)
- Operating temperature: 0 to 55 C
- Non-operating temperature: -40 to 70 C
- Operating humidity: 10% to 85% relative humidity
- Non-operating humidity: 10% to 90% relative humidity
- Operating altitude: 3050 m
- Safety: CB, cTUVus, CE
- EMC: CE, FCC, VCCI, ICES, RCM, KC
- RoHS: Compliant
FAQs
Q: Does this adapter need a software licence?
A: No. No software licence is required for the adapter itself. Drivers (MLNX_OFED and WinOF-2) and firmware are provided by NVIDIA.
Q: Can this card run both InfiniBand and Ethernet?
A: Yes. As a VPI adapter, the QSFP56 port can run either HDR InfiniBand or 200GbE, and it also negotiates lower InfiniBand and Ethernet speeds with compatible cables.
Q: What PCIe slot does it need?
A: It uses a PCIe Gen4 x16 slot for full 200Gb/s throughput. It is also compatible with Gen3, 2.0 and 1.1 slots.
Q: What power and cooling does it need?
A: Typical power is 19.3W with passive cables, drawn through the PCIe x16 slot. With passive cables it needs airflow of 350 LFM at 55 C ambient, heatsink to port.
Q: What cables and modules does it work with?
A: It works with QSFP56 HDR and 200GbE DAC, AOC and optical modules. Lower-speed HDR100, EDR and 100/50/40/25/10GbE links work via compatible cables or breakouts.
