NVIDIA 900-9X658-0046-SB0 | ConnectX-6 Dx 100GbE OCP 3.0 NIC, Crypto, Host Mgmt
SKU:900-9X658-0046-SB0
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The ConnectX-6 Dx is a single-port 100GbE SmartNIC in the OCP 3.0 Small Form Factor, built for cloud-native and hyperscale deployments, enterprise data centres, cybersecurity workloads, scale-out compute and storage, telco and NFV, and AI and machine learning clusters.
This variant has a single QSFP56 port that accepts QSFP28 100GbE optics and cables, and it connects to the host over PCIe 4.0 x16, which is backward compatible with Gen 3.0, 2.0 and 1.1. It supports Ethernet data rates from 1 to 200 Gb/s and draws a typical 16.9 W in active mode with passive cables, with a maximum of 24 W. Crypto and Secure Boot are enabled, host management is included, and the card uses a thumbscrew (pull tab) bracket. No software licence is required for basic operation.
It fits OCP 3.0 SFF server slots and supports QSFP28 and QSFP56 DAC, AOC and transceivers from the NVIDIA LinkX range. Drivers are available for Linux (NVIDIA OFED), Windows (WinOF-2) and VMware ESXi.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Hardware-accelerated vSwitch and vRouter (ASAP2) with full OVS data-plane offload
- SR-IOV and VirtIO acceleration, up to 1K VFs per port and 8 physical functions
- Inline hardware IPsec and TLS encryption and decryption (AES-GCM 128/256), plus AES-XTS data-at-rest encryption
- Hardware root-of-trust with secure firmware update
- RoCE v1/v2, zero-touch RoCE and GPUDirect support
- NVMe-oF target and initiator offloads, plus iSER, SRP, NFS RDMA and SMB Direct
- Advanced PTP (IEEE 1588v2) and time-sensitive networking
- NC-SI, MCTP and PLDM management for BMC integration
- Remote boot over Ethernet and iSCSI, with UEFI and PXE
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- OPN: MCX623435AC-CDAB
- Form factor: OCP 3.0 Small Form Factor (SFF)
- Dimensions: 115 mm x 76 mm (4.52 in x 2.99 in)
- Ports: 1 x QSFP56 (backward compatible with QSFP28)
- Ethernet data rates: 1/10/25/40/50/100/200 Gb/s
- Host interface: PCIe Gen 4.0 x16, 16.0 GT/s SERDES (Gen 3.0/2.0/1.1 compatible)
- Capabilities: Crypto enabled, Secure Boot enabled, with Host Management
- Bracket: Thumbscrew (pull tab)
- Voltage: 3.3VAUX, 12V
- Typical power (passive cables): 16.9 W active, 5.6 W standby
- Maximum power (passive cables): 24 W active, 11.4 W standby
- Maximum power available through QSFP56 port: 5 W
- Platform security: Hardware root-of-trust and secure firmware update
- Maximum DPDK message rate (family): up to 215 Mpps
FAQs
Q: Does this card need a software licence?
A: No licence is required for basic operation. Hardware Crypto and Secure Boot are enabled on this SKU. NVIDIA notes a potential bandwidth limitation when using crypto at 100Gb/s or higher with IPsec traffic.
Q: Will it fit a standard PCIe low-profile slot?
A: No. This is an OCP 3.0 Small Form Factor card and it needs an OCP 3.0 SFF server slot. It is not a standard PCIe low-profile card.
Q: What optics and cables work with the QSFP56 port?
A: The QSFP56 cage accepts QSFP28 and QSFP56 DAC cables, AOC cables and transceivers, including the NVIDIA LinkX range. Up to 5 W is available to the port module.
Q: What power does it draw?
A: It draws 3.3VAUX and 12V from the OCP 3.0 slot, with a typical 16.9 W and a maximum of 24 W in active mode with passive cables. Standby is 5.6 W typical and 11.4 W maximum.
Q: Which operating systems have driver support?
A: NVIDIA OFED is available for Linux and WinOF-2 for Windows, and VMware ESXi has a native driver.
