NVIDIA 900-9X625-0053-SB0 | ConnectX-6 Lx OCP 3.0 Dual 25G SFP28 Adapter, No Crypto
SKU:900-9X625-0053-SB0
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The ConnectX-6 Lx is a dual-port 10/25GbE SFP28 SmartNIC in the OCP 3.0 small form factor, built for enterprise, cloud, hyperscale and telco data centres that need 25GbE with SDN and RoCE acceleration inside an OCP 3.0 server.
This variant has two SFP28 ports running at 10, 25 or 1 GbE and a PCIe Gen 4.0 x8 host interface that also runs at Gen 3.0. It delivers line-rate message rates up to 75 Mpps and supports SR-IOV with up to 8 physical functions. It is the non-crypto version with host management and a thumbscrew (pull tab) bracket, so there is no IPsec crypto offload or secure boot enforcement. No licence or subscription is required. The card draws power from the OCP 3.0 connector (3.3VAUX and 12V), with typical consumption of 11.8 W using passive cables and a maximum of 16.7 W with 1.5 W active cables.
The SFP28 cages accept 25G SFP28 and 10G SFP+ optics as well as DAC and AOC cables, and the card fits OCP Spec 3.0 SFF server slots. Supported operating systems and driver versions are listed in the NVIDIA firmware and driver release notes.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- ASAP2 accelerated switching and packet processing with SDN data plane offload (OVS)
- Advanced RoCE v1/v2, including Zero Touch RoCE without PFC or ECN
- Overlay tunnel offloads for VXLAN, NVGRE and GENEVE
- Stateful connection tracking for L4 firewall offload
- Hardware Root-of-Trust with secure firmware update
- NVMe-oF target offloads and GPUDirect support
- PTP (IEEE 1588v2) hardware clock and timestamping with time-based SDN acceleration
- Remote boot over Ethernet and iSCSI, with UEFI and PXE support
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Ports: 2 x SFP28 (10/25 GbE)
- Ethernet data rate: 10/25 Gb/s (supports 25, 10 and 1 GbE)
- Host interface: PCIe Gen 4.0 x8, SERDES at 16.0 GT/s, backward compatible with Gen 3.0
- Form factor: Small Form Factor (SFF) OCP 3.0
- Dimensions: 115.00 mm x 76.00 mm (4.52 in x 2.99 in)
- Bracket: Thumbscrew (pull tab)
- Crypto: No (non-crypto version, no secure boot enforcement)
- Message rate: up to 75 Mpps at line rate
- Voltage: 3.3VAUX, 12V
- Typical power (passive cables, active mode): 11.8 W
- Maximum power (passive cables): 13.4 W active mode, 9.2 W standby mode
- Maximum power (1.5 W active cables): 16.7 W active mode, 10.9 W standby mode
- Maximum power available through each SFP28 port: 1.5 W
- Operating temperature: 0 to 55 C
- Non-operating temperature: -40 to 70 C
- Operating humidity: 10% to 85% relative humidity
- Non-operating humidity: 10% to 90% relative humidity
- Virtualisation: SR-IOV, up to 8 PFs
- Management: SMBus 2.0, NC-SI, MCTP over SMBus and PCIe, PLDM for monitor, control and firmware update
FAQs
Q: Does this adapter need a licence or subscription?
A: No. No licence or subscription is required. This SKU is the non-crypto version, so it has no IPsec crypto offload and does not enforce secure boot.
Q: How is this card powered?
A: It is powered from the OCP 3.0 connector (3.3VAUX and 12V). Typical power is 11.8 W with passive cables, and the maximum is 13.4 W with passive cables or 16.7 W with 1.5 W active cables.
Q: What server slots and optics does it work with?
A: It fits OCP Spec 3.0 SFF server slots with a PCIe Gen 4.0 x8 interface, also working at Gen 3.0. The SFP28 cages accept 25G SFP28 and 10G SFP+ optics as well as DAC and AOC cables.
Q: Can it run at 10GbE as well as 25GbE?
A: Yes. The two SFP28 ports support 25, 10 and 1 GbE, so the card can connect to both 25G and 10G infrastructure.
Q: How does this SKU differ from other ConnectX-6 Lx OCP 3.0 variants?
A: This variant is the non-crypto model with host management and a thumbscrew (pull tab) bracket. Crypto-enabled models add inline IPsec acceleration and secure boot enforcement, which this SKU does not have.
