NVIDIA 900-9D3D4-00EN-HA0 | BlueField-3 B3140H DPU, 400G QSFP112, Crypto, Tall Bracket
SKU:900-9D3D4-00EN-HA0
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The BlueField-3 B3140H is a single-slot half-height half-length DPU and SuperNIC with one QSFP112 cage, supporting 400Gb/s NDR InfiniBand or 400GbE, with Ethernet as the default mode. It is built for AI and cloud data centres, and for bare-metal and virtualised servers that need infrastructure offload, security isolation and 400G connectivity.
The card pairs 8 Arm cores and 16GB of on-board DDR with an integrated BMC, so networking, storage and security services run on the card instead of the host CPU. It connects to the server over a PCIe Gen5 x16 interface and is crypto enabled. This SKU is fitted with a tall bracket and is part of the E-Series B3140H range.
The QSFP112 cage takes 400G optics and DACs, and the card needs a PCIe Gen5 x16 slot in the host server.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Hardware offload and acceleration of networking, storage and security services
- Programmable Arm cores run infrastructure software on the card
- Hardware root-of-trust and crypto acceleration
- InfiniBand NDR and 400GbE supported on the same QSFP112 port
- Integrated BMC for out-of-band management
- Single-slot half-height half-length design suits dense server builds
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Part number: 900-9D3D4-00EN-HA0
- Series: BlueField-3 B3140H, E-Series
- Network ports: 1 x QSFP112
- Maximum speed: 400Gb/s
- Supported protocols: InfiniBand NDR, 400GbE (Ethernet is the default mode)
- Host interface: PCIe Gen5 x16
- Arm cores: 8
- On-board memory: 16GB DDR
- Management: integrated BMC
- Crypto: enabled
- Form factor: single-slot HHHL
- Bracket: tall bracket
FAQs
Q: Does it run InfiniBand or Ethernet by default?
A: The default mode is 400GbE. The single QSFP112 port also supports NDR InfiniBand at up to 400Gb/s.
Q: What host slot does it need?
A: It needs a PCIe Gen5 x16 slot in the host server to reach its full 400Gb/s bandwidth.
Q: What optics or cables fit the port?
A: The port is a QSFP112 cage, so it uses QSFP112 optics and DACs for 400G connections.
Q: How does this SKU differ from other B3140H variants?
A: This SKU is crypto enabled, has 8 Arm cores and 16GB DDR, and is fitted with a tall bracket. Its default mode is 400GbE.
