• Cisco catalyst 9500 series switch with sleek white chassis multiple ethernet ports and usb connectors back view
1 1

Cisco

Cisco CW9800L-MCG | Campus Gateway Wireless Controller, 10G, 2x SFP+

CW9800L-MCG

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The CW9800L-MCG is the smaller of the two Cisco Campus Gateway models. It is a cloud-native wireless controller managed through the Meraki dashboard, built for campus networks that need seamless roaming at scale. It suits large campuses, organisations moving from on-premises controllers to cloud-managed wireless, and designs that use DMZ guest tunnelling, multi-site roaming or disaster recovery.

Through a standalone appliance it provides up to 10 Gbps of throughput, rising to 20 Gbps in a cluster of two. Data connectivity is 2 x 1/10 Gbps SFP+ ports, with a 1 Gbps RJ-45 redundancy port for clustering and an RJ-45 service port. Scale is up to 1,000 access points and 10,000 clients on current software, with 500 access points on releases before 32.2.3. Power comes from a single 12V DC, 110 W external AC adapter, with optional redundant power through the CW9800L-RPS=. The CW9800H1-MCG is the larger model, with 100 Gbps and 12,000 access point scale.

It works with Meraki MR and CW series access points, including Wi-Fi 6 models (MR36, MR36H, MR44, MR46, MR46E, MR56, MR76, MR78, MR86), Wi-Fi 6E models (MR57, CW9162, CW9163, CW9164, CW9166) and all Wi-Fi 7 models. Release MR32.2 or later is required on both the gateway and the access points.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Cloud-managed through the Meraki dashboard with simple Day 0 onboarding
- Seamless roaming at scale for large campus networks
- High availability through a two-appliance cluster using the redundancy port
- Adaptive Policy with Security Group Tags for macro and micro segmentation
- Multi-network roaming through network groups in a Meraki organisation
- DMZ guest tunnelling, remote site support and disaster recovery with multiple clusters
- Same hardware platform as the on-premises Catalyst CW9800 controllers, easing migration to cloud-managed wireless

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Throughput: up to 10 Gbps standalone, 20 Gbps in a cluster of two
- Access point scale: up to 1,000 APs (500 APs on releases before 32.2.3)
- Client scale: 10,000 clients
- Data ports: 2 x 1/10 Gbps SFP+
- Redundancy port: 1 x 1 Gbps RJ-45
- Service port: 1 x RJ-45
- Power: single 12V DC, 110 W 120/240 V AC adapter
- Redundant power option: CW9800L-RPS=
- Cluster size: one or two Campus Gateway appliances
- Minimum release: Campus Gateway MR32.2 and Access Points MR32.2
- Supported SFP modules: GLC-TE, GLC-LH-SMD, GLC-SX-MMD
- Supported SFP+ modules: SFP-10G-SR, SFP-10G-SR-S, SFP-10G-LR, SFP-10G-LR-S, SFP-10G-SR-I, SFP-10G-ZR-I, SFP-10G-BXD-I, SFP-10G-BXU-I, Finisar FTLX1471D3BCL, Finisar FTLX8574D3BC
- Supported DAC/AOC cables: SFP-H10GB-CU2.5M, CU3M, CU5M, ACU7M, ACU10M, SFP-10G-AOC1M to 10M

FAQs

Q: Does the Campus Gateway need a licence?
A: The gateway itself needs no device licence. The access points it supports need a Meraki Enterprise or Advanced tier cloud licence, while Wi-Fi 7 access points need a Cisco Networking subscription at Essentials or Advantage tier.

Q: Which access points does it support?
A: It supports Wi-Fi 6 models MR36, MR36H, MR44, MR46, MR46E, MR56, MR76, MR78 and MR86, Wi-Fi 6E models MR57, CW9162, CW9163, CW9164 and CW9166, and all Wi-Fi 7 models.

Q: How does it differ from the CW9800H1-MCG?
A: The CW9800L-MCG provides up to 10 Gbps with 2 x 1/10G SFP+ ports and up to 1,000 APs. The CW9800H1-MCG provides 100 Gbps with 4 x 25G SFP28 and 8 x 10G SFP+ ports and scales to 12,000 APs.

Q: Which optics and cables can be used on the SFP+ ports?
A: Supported modules include GLC-TE, GLC-LH-SMD, GLC-SX-MMD, the SFP-10G-SR and SFP-10G-LR families, Finisar SR and LR optics, and 10G DAC and AOC cables from 1 m to 10 m. Use at least two uplink ports of the same speed and type to the upstream switch.

Q: Can it be run as a redundant pair?
A: Yes. One or two Campus Gateway appliances can form a cluster using the 1 Gbps RJ-45 redundancy port, giving high availability and up to 20 Gbps of clustered throughput.

Q: Can I claim it on my Meraki dashboard?
A: Yes. Every Meraki device XS Network Tech supplies can be claimed on your Meraki dashboard.
