Cisco

Cisco C9800-1X40GE | Catalyst 9800-80 1-Port 40GE QSFP+ Uplink Module

SKU:C9800-1X40GE

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The C9800-1X40GE is a hot-swappable, single-port 40GE QSFP+ uplink module for the Catalyst 9800-80 wireless controller. It suits large enterprise, campus and data centre WLAN deployments that need more uplink capacity than the chassis provides on its own.

The module adds one 40GE QSFP+ port alongside the fixed 10G uplinks on the host chassis, which offers 8x 10G or 6x 10G plus 2x 1G SFP+/SFP. It accepts 10G, 40G and 100G QSFP transceivers listed for the 9800-80, including QSFP-40G-SR4, QSFP-40G-LR4, QSFP-40G-ER4, QSFP-40G-SR-BD, QSFP-100G-SR4-S and QSFP-100G-LR4-S. It is powered from the chassis and has no separate power input. Online insertion and removal is supported.

The module is for the Catalyst 9800-80 only, not the 9800-40 or 9800-L, and the host controller must run Cisco IOS XE 16.10.1 or later. The module itself needs no licence. Access points connecting to the controller require a Cisco DNA Essentials or Advantage subscription per AP, managed through a Smart Account.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Hot-swappable uplink module for the Catalyst 9800-80
- Adds 40GE QSFP+ connectivity alongside the fixed 10G uplinks of the chassis
- Same modular uplink family as C9800-18X1GE, C9800-10X10GE, C9800-2X40GE and C9800-1X100GE
- Accepts 10G, 40G and 100G QSFP transceivers listed for the 9800-80
- Powered by the chassis with no separate power input
- Host controller runs Cisco IOS XE with programmable APIs and model-driven telemetry

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Datasheet

Technical Specifications

- Module description: Cisco Catalyst 9800-80 1 Port 40GE Module
- Ports: 1 x 40GE QSFP+
- Role: Optional modular uplink for the Catalyst 9800-80
- Hot-swappable: Yes
- Online insertion and removal: Supported for SFP, SFP+ and QSFP
- Supported QSFP optics: QSFP-40G-SR4, QSFP-40G-LR4, QSFP-40GE-LR4, QSFP-40G-ER4, QSFP-40G-SR4-S, QSFP-40G-LR4-S, QSFP-40G-SR-BD, QSFP-40G-BD-RX, QSFP-100G-SR4-S, QSFP-100G-LR4-S
- Host chassis fixed uplinks: 8x 10G or 6x 10G + 2x 1G SFP+/SFP
- Host chassis maximum power consumption with modules: 600 W
- Host chassis form factor: 2RU
- Host chassis dimensions (W x D x H): 43.94 x 52.07 x 8.81 cm
- Host chassis weight: 14.29 kg
- Host chassis maximum access points: Up to 6000
- Host chassis maximum clients: 64,000
- Minimum host software: Cisco IOS XE 16.10.1 or later

FAQs

Q: Which controllers is the C9800-1X40GE compatible with?
A: It is for the Catalyst 9800-80 wireless controller only. It is not for the 9800-40 or 9800-L. The host must run Cisco IOS XE 16.10.1 or later.

Q: Does the module need its own licence?
A: No. The module itself needs no licence. Access points connecting to the host controller require a Cisco DNA Essentials or Advantage subscription per AP, managed through a Smart Account.

Q: How is the module powered?
A: It draws power from the Catalyst 9800-80 chassis and has no separate power input. The chassis maximum power consumption with modules is 600 W.

Q: Which optics can I use in the 40GE port?
A: Genuine options listed for the 9800-80 include QSFP-40G-SR4, QSFP-40G-LR4, QSFP-40GE-LR4, QSFP-40G-ER4, QSFP-40G-SR-BD, QSFP-100G-SR4-S and QSFP-100G-LR4-S.

Q: Can the module be fitted while the controller is running?
A: Yes. The uplink modules are hot-swappable and the controller supports online insertion and removal.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
