• HPE ProLiant DL380 Gen10 24-bay SFF storage server with 12x 2.4TB SAS HDD
1 1

HPE

HPE P79247-B25 | SFF 24-bay | Dual 16Gb FC (8 host ports) | 12x 2.4TB 2.5in 12G SAS HDD (~28.8TB raw) | 4x 16Gb FC SFP+ optics | 12G SAS backend | RAID 0/1/10/5/6

P79247-B25

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.

 Trade supply only. Server & GPU quote requests need a company name, ABN and work email address. We do not quote Gmail, Outlook or Hotmail addresses, or supply for home use.

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Custom Built Servers

Need a different spec, quantity or configuration?

We build configured-to-order refurbished servers from Cisco, Dell, HPE, NVIDIA Lenovo and Supermicro. Tell us what you need and we'll come back with options within 24 hours.

Configure your server now →

Description

Compact 2U SFF array pre-populated with 12x 2.4TB 12G SAS enterprise HDDs and dual active-active 16Gb Fibre Channel controllers for highly available block storage. The 24-bay chassis leaves room to scale capacity, while included 16Gb FC SFP+ optics accelerate deployment. Supports standard RAID levels, thin provisioning, and mixed media pools (HDD/SSD) for flexible performance and capacity tuning.

Features

- Dual active-active controllers for continuous access
- Eight 16Gb FC host ports for ample SAN connectivity
- Enterprise 12G SAS HDDs for dependable performance
- 24-bay SFF chassis with room to scale
- Flexible data services: thin provisioning, snapshots, replication options
- SSD-ready for performance tiering and cache acceleration
- Simple web-based management and fast deployment with included FC SFPs

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Form factor: 2U SFF (24-bay), 12 bays populated
- Drives included: 12x 2.4TB 2.5" 12G SAS enterprise HDD (≈28.8TB raw)
- Controller architecture: Dual active-active
- Host interface: 16Gb Fibre Channel
- Host ports: 8 total (4 per controller)
- Included optics: 4x 16Gb FC SFP+ transceivers
- Drive backend: 12G SAS
- RAID levels: 0, 1, 10, 5, 6
- Thin provisioning and snapshots supported (licensing/features may vary)
- Supports mixing HDD and SSD with tiering/caching (SSDs and licenses may be required)
- Management: Browser-based GUI and CLI
- Expansion: Additional SFF drive enclosures supported

FAQs

Q: Is the 29TB capacity raw or usable?
A: It is raw capacity. Usable capacity depends on RAID level, system overhead, and data services.

Q: How many Fibre Channel host ports are available?
A: There are 8x 16Gb FC host ports total (4 per controller) in a dual-controller configuration.

Q: Are FC SFPs included?
A: Yes. 4x 16Gb FC SFP+ optics are included as listed.

Q: Can I add SSDs later for tiering?
A: Yes. You can mix SSDs with HDDs and enable tiering/caching; appropriate licenses and SSDs are required.

Q: Can I expand capacity beyond the included 12 drives?
A: Yes. The 24-bay chassis has empty slots and also supports external expansion enclosures.
