HPE P77924-B21 | MicroServer Gen11 330W External Power Adapter, C13
SKU:P77924-B21
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The 330W External Power Adapter is the higher-power option for the HPE ProLiant MicroServer Gen11. It suits small-office, branch-office and edge deployments where a processor above 65W or other higher-power options are fitted.
This is a non-redundant, single external adapter rated at 330W, which keeps the server chassis compact. It connects with a C13 power cord, whereas the 180W adapter option uses a C5 cord. Physical size is 85 mm high, 185 mm wide and 31 mm deep, with an approximate weight of 1.11 kg.
One adapter is selected per server. It is the alternative to the 180W External Power Adapter (P74395-B21), which covers lower-power configurations. HPE recommends using the HPE Power Advisor tool to check the power requirements of a specific configuration.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Designed for MicroServer Gen11 configurations with higher-power options
- Required when using processors above 65W
- Alternative to the 180W adapter (P74395-B21) for lower-power configurations
- Non-redundant external adapter keeps the chassis compact
- Uses a C13 power cord
- HPE Power Advisor tool can be used to check the power needs of a configuration
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Part number (option kit): P77924-B21
- Product type: Power adapter
- Power rating: 330W
- Redundancy: Non-redundant external power adapter
- Device supported: HPE ProLiant MicroServer Gen11
- Power cord type: C13
- Height: 85 mm (3.35 in)
- Width: 185 mm (7.28 in)
- Depth: 31 mm (1.22 in)
- Weight (approx.): 1.11 kg (2.45 lb)
- Spares part no.: 874739-001
- Renew option kit no.: P77924R-B21
FAQs
Q: When do I need the 330W adapter instead of the 180W adapter?
A: The 330W adapter is required when the MicroServer Gen11 is fitted with a processor above 65W or other higher-power options. Lower-power configurations can use the 180W adapter (P74395-B21).
Q: Which server does this power adapter work with?
A: It is an option for the HPE ProLiant MicroServer Gen11. One adapter is selected per server.
Q: What power cord does it use?
A: The 330W adapter pairs with a C13 power cord. The 180W adapter uses a C5 cord.
Q: Is this a redundant power supply?
A: No. It is a single, non-redundant external power adapter.
Q: How do I confirm the power requirement of my configuration?
A: HPE recommends the HPE Power Advisor tool to check the power requirements of a specific MicroServer Gen11 configuration before choosing an adapter.
