• Cisco UCS-PSU-64108-AC black hot-swap AC PSU with sleek multi-port design
1 1

Cisco

Cisco UCS-PSU-64108-AC | UCS 6400 1200W AC Power Supply, 100-240VAC

UCS-PSU-64108-AC

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This 1200 W AC power supply module is built for the Cisco UCS 64108 2RU Fabric Interconnect in the UCS 6400 Series. It is a hot-swappable, field-replaceable unit used to provide redundant AC power to top-of-rack fabric interconnects in data centre Cisco UCS and HyperFlex deployments.

The module accepts auto-ranging 100-240 VAC input across a 90 to 264 VAC range, with a maximum input current of 11 A at 100 VAC or 7 A at 200 VAC. It delivers up to 1200 W of output at 12 VDC with a 12 VDC standby rail, and holds up for 12 ms at 50% load. Efficiency is rated 80Plus Platinum and Climate Savers Platinum, and the unit is RoHS compliant. The 64108 uses up to two identical power supplies, and AC and DC modules cannot be mixed within one chassis.

This part is specific to the UCS 64108 Fabric Interconnect and is not interchangeable with the 650 W UCS-PSU-6332-AC used in the UCS 6454. No licence is required for the power supply itself.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Hot-swappable, field-replaceable power supply for the UCS 64108 2RU fabric interconnect
- Supports a redundant two-PSU configuration
- Auto-ranging AC input from 100 to 240 VAC
- 80Plus Platinum certified high efficiency
- Standard airflow from front (PSU/fan-side) to back (port-side exhaust)
- RoHS compliant

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Maximum output per power supply: 1200 W
- Input voltage range: 90 to 264 VAC (100-240 VAC auto-ranging)
- Maximum AC input current: 11 A at 100 VAC, 7 A at 200 VAC
- Maximum holdup time: 12 ms at 50% load
- Output voltage: 12 VDC
- Standby voltage: 12 VDC
- Efficiency rating: Climate Savers Platinum (80Plus Platinum certified)
- Hot swappable: Yes
- RoHS compliance: Yes
- Frequency (UCS 64108 system): 50 to 60 Hz
- Power supplies per fabric interconnect: Up to 2, two identical AC or DC
- Typical operating power (UCS 64108 system): 404 W
- Maximum power, AC (UCS 64108 system): 1200 W
- System efficiency, AC: 95 to 98% (50 to 100% load)
- Airflow (UCS 64108 system): Standard airflow, front (PSU/fan-side) to back (port-side exhaust)

FAQs

Q: Which Cisco chassis does this power supply fit?
A: It is for the Cisco UCS 64108 Fabric Interconnect (UCS-FI-64108 and UCS-FI-64108-U). It is not interchangeable with the UCS-PSU-6332-AC (650 W) used in the UCS 6454.

Q: Does it need a licence or subscription?
A: No. The power supply itself does not require a licence.

Q: How many power supplies does a UCS 64108 use?
A: The fabric interconnect takes up to two identical power supplies for redundancy. AC and DC modules cannot be mixed in the same chassis.

Q: What input voltage does it accept?
A: It accepts auto-ranging 100-240 VAC across a 90 to 264 VAC range, at 50 to 60 Hz. Maximum input current is 11 A at 100 VAC and 7 A at 200 VAC.

Q: Can I hot-swap it while the fabric interconnect is running?
A: Yes. The module is hot swappable, so a power supply can be replaced in a redundant configuration without taking the system offline.
