• Cisco VG202XM voice gateway with dual FXS ports and Ethernet USB
1 1

Cisco

Cisco VG202XM | VG200 2-Port FXS Analog Voice Gateway, 256 MB DRAM

VG202XM

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The VG202XM is a compact, standalone Cisco IOS-based analog voice gateway from the VG200 range. It connects existing analog phones, fax machines and modems to an IP telephony network, which makes it a practical fit for branch offices and small sites that need two analog lines. It signals using SIP or SCCP and works with Cisco Unified Communications Manager and Unified Communications Manager Express.

This XM model provides 2 FXS analog voice ports on RJ-11 connectors with loop-start or ground-start signalling, plus 2 x 10/100BASE-T Fast Ethernet ports. It carries 256 MB of DRAM and 128 MB of flash memory that holds the Cisco IOS image, which sets it apart from the standard VG202 with 128 MB of DRAM. An RJ-45 console/AUX port (EIA/TIA-232) is provided for management and RADIUS is supported.

Power is supplied by an external AC adapter taking 100-240 VAC at 50/60 Hz, and the unit has no PoE. The chassis measures 8.8 x 8.1 x 1.8 in and is wall mountable. It is the 2-port counterpart of the 4-port VG204XM.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Standalone Cisco IOS software-based analog gateway for low-density two-line deployments
- SIP features plus IOS fax, modem and security features
- Works with Cisco Unified Communications Manager and Unified Communications Manager Express over SCCP or SIP
- Lets existing analog phones, fax machines, modems, voicemail systems and speakerphones be used on IP networks
- RJ-11 analog interfaces combined with Cisco IOS manageability
- Anti-counterfeiting cookie configuration in boot flash
- Kensington security slot and chassis ground connection

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- FXS analog voice ports: 2 (RJ-11)
- FXS signalling: Loop-start or ground-start (on-premises only)
- Ethernet interfaces: 2 x 10/100BASE-T (802.3), RJ-45
- Console/AUX port: EIA/TIA-232 asynchronous serial (DCE), RJ-45
- RAM (CPU memory): 256 MB
- Flash memory: 128 MB (holds Cisco IOS image)
- Signalling protocols: SIP, SCCP
- Management features: RADIUS support
- AC input voltage: 100 to 240 VAC
- AC input current (max): 0.5 A
- Frequency: 50 to 60 Hz
- DC input voltage: 12 V
- Dimensions (W x D x H): 8.8 x 8.1 x 1.8 in
- Operating humidity: 10-85% (non-condensing)
- Form factor: External/standalone, wall mountable
- Compliance: UL 60950, IEC 60950, FCC, ICES-003 Class B, CISPR 22 Class B, CISPR 24, EN55022 Class B, EN55024, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN50082-1

FAQs

Q: Does the VG202XM need a separate licence?
A: It runs Cisco IOS software from a 128 MB image held in onboard flash. A separate subscription or licence tier is not part of its specification.

Q: How is the VG202XM powered?
A: It uses an external AC adapter that accepts 100-240 VAC at 50/60 Hz, with a maximum input current of 0.5 A. The unit has no PoE.

Q: What call control platforms does it work with?
A: It interoperates with Cisco Unified Communications Manager and Cisco Unified Communications Manager Express, using either SCCP or SIP signalling.

Q: How does the VG202XM differ from the VG202?
A: The XM model has 256 MB of DRAM, while the standard VG202 has 128 MB. Both share the same chassis and offer 2 FXS ports.

Q: What is the difference between the VG202XM and the VG204XM?
A: The VG202XM provides 2 FXS analog ports and the VG204XM is its 4-port counterpart, so choose by the number of analog devices you need to connect.
