• Cisco UCS VIC 1485 4x25G mezzanine card with green circuit board and processor
1 1

Cisco

Cisco UCSX-V4-Q25GME | UCS VIC 14825 4x25G Mezzanine Adapter, X Compute Node

UCSX-V4-Q25GME

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Cisco UCS VIC 14825 is a quad-port 25G Ethernet and FCoE mezzanine adapter for Cisco UCS X-Series compute nodes, part of the UCS Virtual Interface Card 1400 family. It presents PCIe-compliant NICs and HBAs to the host that are configured dynamically through policy, which suits virtualised and bare-metal data centre workloads that need unified LAN and SAN connectivity.

The card provides 4 x 25-Gbps ports and uses a PCIe 3.0 x16 interface for 128 Gb/s of host throughput. It supports 256 virtual interfaces, with approximately eight reserved for internal use, and is built on a Cisco custom ASIC rated for more than 900,000 IOPS. Maximum power consumption is 42.4 W, and the mezzanine form factor measures 5.71 x 5.19 x 1.47 in. It is managed through Cisco UCS Manager or Cisco Intersight.

The adapter links to the chassis fabric through the UCSX-V4-BRIDGE connector to the Intelligent Fabric Module. It works with the UCSX-I-9108-25G and UCSX-I-9108-100G modules and with UCS FI-6664, FI-6536, FI-64108 and FI-6454 fabric interconnects. The X210c M6 compute node is the listed supported server, and the minimum UCSM release is 4.2(1).

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Policy-based, stateless server infrastructure with PCIe interfaces dynamically configured as NICs or HBAs
- Cisco SingleConnect unifies LAN, SAN and management over a single network
- 256 dynamic virtual adapters and interfaces without requiring SR-IOV from the OS or hypervisor
- Cisco Data Center VM-FEX technology
- Hardware-based fabric failover for a redundant path to the Fabric Interconnect
- Advanced capabilities including SR-IOV, usNIC, iSCSI boot, DPDK, NetFlow, NPIV, VXLAN, NVGRE, GENEVE and RoCEv2
- OS and hypervisor support including VMware vSphere, Microsoft Windows, RHEL, SLES, Ubuntu and Citrix XenServer
- Centralised management through UCS Manager or Intersight

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Ports: 4 x 25-Gbps Ethernet / FCoE
- Form factor: Mezzanine, PCIe 3.0 x16 (128 Gb/s)
- Virtual interfaces: 256 (approx. 8 reserved for internal use)
- ASIC: Cisco UCS custom ASIC
- Performance: 900,000+ IOPS
- Low latency: usNIC support, as low as 1 microsecond in back-to-back VIC connections
- Maximum power consumption: 42.4 W
- Length: 5.71 in
- Width: 5.19 in
- Height: 1.47 in
- Ethernet standards: 10/25/40/100-Gigabit Ethernet, IEEE 802.3x, 802.1q VLAN, 802.1p, 802.1Qaz, 802.1Qbb, prestandard 802.1BR
- Jumbo frames: up to 9KB
- Storage protocols: SCSI-FCP, T11 FCoE, FC-NVMe, NVMe over Fabrics with RoCEv2
- Lossless Ethernet: Priority Flow Control (PFC)
- Fabric connection: UCSX-V4-BRIDGE connector to the Intelligent Fabric Module
- Supported IFMs: UCSX-I-9108-25G, UCSX-I-9108-100G (with FI-6536)
- Supported fabric interconnects: UCS-FI-6664, UCS-FI-6536, UCS-FI-64108, UCS-FI-6454
- Supported server: UCS X210c M6
- Minimum software release: UCSM 4.2(1)
- Management: Cisco UCS Manager or Cisco Intersight

FAQs

Q: Does the UCS VIC 14825 need a separate licence?
A: No separate licence is stated for the adapter itself. It is managed through Cisco UCS Manager or Cisco Intersight, and their own licensing applies.

Q: Which compute node does this mezzanine adapter fit?
A: It is a mezzanine card for Cisco UCS X-Series compute nodes. The X210c M6 is the listed supported server.

Q: What is needed to connect it to the chassis fabric?
A: The UCSX-V4-BRIDGE connector is required to link the card to the Intelligent Fabric Module. It works with the UCSX-I-9108-25G and UCSX-I-9108-100G modules.

Q: Which fabric interconnects does it support?
A: It supports the UCS FI-6664, FI-6536, FI-64108 and FI-6454. The minimum software release is UCSM 4.2(1).

Q: How much power does the adapter draw?
A: Maximum power consumption is 42.4 W. It is powered from the mezzanine slot of the X-Series compute node.
