Cisco UCSX-PSU-2800AC-D | UCS X9508 2800W AC Dual Voltage Power Supply, Titanium
SKU:UCSX-PSU-2800AC-D
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
This hot-swappable 2800W AC power supply is built for the Cisco UCS X9508 chassis, part of the UCS X-Series Modular System. It converts AC mains to the 54 VDC main output the chassis distributes to its compute nodes, X-Fabric and PCIe or GPU-accelerated nodes. It suits data centre deployments that need N, N+1, N+2 or Grid (N+N) redundancy from separate AC feeds.
The 2800 VAC dual-voltage design accepts 100-127 VAC or 200-240 VAC nominal input at 50-60 Hz. Maximum output is 2800W at 200-240 VAC and 1400W at 100-127 VAC. It is 80+ Titanium certified, draws a maximum of 18 A, and each supply can be connected to a different AC phase. Hold-up time is a minimum of 10 ms at both 1400W and 2800W.
The X9508 chassis has six power supply bays split across two rear AC power entry modules, with IEC320 C20 inlets. A minimum of two supplies is required, four are recommended and six is the maximum. One node needs at least two supplies, two to six nodes need at least four, and seven to eight nodes need six. No licence is required for the power supply itself.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- 54 VDC output allows efficient power delivery to the UCS X9508 chassis
- Supports N, N+1, N+2 and Grid (N+N) redundancy
- Dual-voltage operation from 100-127 VAC or 200-240 VAC sources
- Each power supply can be connected to a different AC phase
- Hot-swappable design for in-service replacement
- 80+ Titanium efficiency rating
- Up to six supplies per chassis to power compute, X-Fabric and GPU-accelerated nodes
- Sizing supported by the Cisco UCS Power Calculator
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Maximum output per PSU: 2800W at 200-240 VAC, 1400W at 100-127 VAC
- Main output voltage: 54 VDC
- AC input voltage: 100-127 VAC and 200-240 VAC nominal (range 90-140 VAC, 180-264 VAC)
- AC input frequency: 50 to 60 Hz nominal (range 47 to 63 Hz)
- Maximum AC input current: 18 A at 90 VAC and 18 A at 180 VAC
- Maximum input VA: 3200 VA at 230 VAC
- Maximum inrush current: 35 A (sub-cycle duration)
- Minimum hold-up time: 10 ms at 1400W and 10 ms at 2800W
- Efficiency rating: 80+ Titanium certified
- Input connector: IEC320 C20 (inlets are on the chassis power entry modules)
- Phase: each supply can be connected to a different phase
- Power supply bays per chassis: 6 (minimum 2 required)
- Chassis power redundancy: nonredundant, N+1, N+2 and Grid (N+N)
- Chassis power entry modules: 2x AC PEM, PEM1 (PSU1-3) and PEM2 (PSU4-6)
- Chassis operating temperature: 10 to 35 C
- Chassis non-operating temperature: -40 to 65 C
- Chassis operating humidity: 10% to 90% non-condensing
FAQs
Q: Does this power supply need a licence?
A: No. The power supply itself needs no licence or subscription. The UCS X9508 chassis it powers is managed through Cisco Intersight or UCS Manager.
Q: How many power supplies does the UCS X9508 need?
A: A minimum of two supplies is required and six is the maximum per chassis. One node needs at least two, two to six nodes need at least four, and seven to eight nodes need six.
Q: What output can I expect on 100-127 VAC input?
A: Output is derated to 1400W at 100-127 VAC. Full 2800W output requires a 200-240 VAC source, so plan the AC feeds accordingly.
Q: Which chassis does this power supply fit?
A: It fits the Cisco UCS X9508 chassis (M6, M7 and M8 generation). The chassis needs its two rear AC power entry modules and an AC power supply keying bracket.
Q: Can I connect the supplies to different AC phases?
A: Yes. Each power supply can be connected to a different phase, which supports Grid (N+N) redundancy across separate feeds.
