Cisco

Cisco UCSX-MRX32G1RE5 | UCS X-Series 32GB DDR5-6400 RDIMM, 1Rx4 (16Gb)

SKU:UCSX-MRX32G1RE5

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This 32GB DDR5 registered DIMM is built for Cisco UCS X-Series M8 compute nodes, including the X210c M8 and X215c M8. It suits memory upgrades or initial configuration of data centre, virtualisation and HCI deployments that need server-class ECC memory.

The module is a single-rank x4 (1Rx4) RDIMM using 16Gb DRAM and operates at 1.1V. On Intel Xeon 6 based nodes it runs at up to 6400 MT/s with one DIMM per channel, dropping to 5200 MT/s at two DIMMs per channel. On 5th Gen AMD EPYC based M8 servers it runs at the CPU memory controller maximum, up to 6000 MT/s. The UCSX- prefix identifies the X-Series PID, while UCS-MRX32G1RE5 is the equivalent for C-Series servers.

For best results, configure memory identically on every CPU socket and keep all DIMMs in the system in the same speed class. Any unused DIMM slot should be filled with a DIMM blank (UCS-DDR5-BLK) to maintain airflow.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- DDR5-6400 performance for Intel Xeon 6 based UCS X-Series M8 compute nodes
- Registered DIMM design with ECC server-class memory
- Also listed for 5th Gen AMD EPYC based M8 servers, running at the CPU memory controller maximum of up to 6000 MT/s
- x4 DRAM organisation, which supports SDDC and ADDDC RAS features that x8 DIMMs do not
- Cisco-qualified memory for UCS M8 platforms
- X-Series PID, with UCS-MRX32G1RE5 as the C-Series equivalent

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Product ID: UCSX-MRX32G1RE5
- PID description: 32GB RDIMM 1Rx4 1.1Volts (16Gb)
- Memory type: Registered DDR5 DIMM (RDIMM)
- Capacity: 32GB
- Ranks per DIMM: 1 (1Rx4)
- DRAM density: 16Gb
- Speed: up to 6400 MT/s at 1 DIMM per channel (Intel Xeon 6)
- Speed at 2 DIMMs per channel: up to 5200 MT/s
- Operating voltage: 1.1 V
- X210c M8 memory layout: eight DIMM channels per CPU, up to 2 DIMMs per channel
- Maximum DIMMs per X210c M8 server: 32 (2-socket)
- Allowed DIMM count (Intel M8): 8 per CPU in 1-CPU, 16 in 2-CPU configurations
- Not supported in 4-CPU configurations
- Maximum X210c M8 memory capacity with 256GB DIMMs: 8TB (32 x 256GB)
- Blank filler for unused slots: UCS-DDR5-BLK

FAQs

Q: Which servers is this memory listed for?
A: It is listed for the Cisco UCS X210c M8 compute node and also appears in the UCS X215c M8 and HCI X210c M8 vSAN spec sheets. It is not supported on the X410c M8.

Q: What is the difference between UCSX-MRX32G1RE5 and UCS-MRX32G1RE5?
A: They are the same 32GB DDR5 RDIMM. The UCSX- prefix is the PID for X-Series compute nodes, while UCS-MRX32G1RE5 is the PID for C-Series rack servers.

Q: What speed will it run at?
A: On Intel Xeon 6 based nodes it runs at up to 6400 MT/s with one DIMM per channel and up to 5200 MT/s at two DIMMs per channel. On AMD EPYC based M8 servers it runs at the CPU memory controller maximum, up to 6000 MT/s.

Q: Can I mix it with other DIMM types?
A: Memory on every CPU socket must be configured identically, and all DIMMs in a system must be the same speed class. DDR5-6400 RDIMM and DDR5 MRDIMM-8800 cannot be mixed.

Q: Do I need to fill every DIMM slot?
A: No, but any empty DIMM slot must be populated with a DIMM blank (UCS-DDR5-BLK) to maintain airflow.
